▶ EngineEngine Manufacturer Kubota Daedong Engine Model V2403-CR-TE4 3FT-THL4-U Engine Type 4-cylinder in-line, common rail direct injection, turbocharged diesel Turbocharged diesel No. of Cylinders 4 3 Displacement 148.5 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2750 rpm Engine Power (Gross) 57.9 hp 57.7 hp PTO Power 50 hp 45.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, pressurized radiator with recovery tank Liquid-cooled Air Cleaner Dry paper dual element, 8 in diameter, pre-cleaner standard Dry type, replaceable Fuel System Common rail direct injection Common rail direct injection Alternator 45 A 75 A, 12 V ▶ HydraulicsPump Type Gear pump Not Published Implement Flow 10.6 gpm 9.6 gpm Steering Flow 6.1 gpm 6.9 gpm Total Hydraulic Flow 16.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.5 gpm 16.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (SCD) 1 pair No. of Optional Remote Valves 2 optional (3 maximum) 1 pair (2nd pair optional) ▶ Fluid CapacityFuel Tank Capacity 17.7 gal 12.7 gal Coolant Capacity 8.5 qt 3.5 qt Crankcase Capacity 7.6 qt 7.8 qt Transmission / Hydraulic System Capacity 50.7 qt Not Published Front Axle Fluid Capacity No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) 5.9 qt ▶ PTO & HitchPTO Type Hydraulic independent PTO, self-modulating multi-plate wet clutch with brake Independent PTO Rear 540 rpm (540/540E optional) 540 rpm Mid-PTO Availability Not Published Optional: 2119 rpm Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity 4189 lb 2716 lb Hitch Lift Capacity (at 24”) 3307 lb 2716 lb Lift Control Type Position control Hydraulic Position Control System ▶ Transmission & DrivetrainTransmission Type Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R 3-Range HST No. of Speeds 8F/8R Infinite forward and reverse (3-range) Max Travel Speed (Forward) 18.2 mph 18.0 mph Max Travel Speed (Reverse) 18.6 mph 12.6 mph Clutch Multiple wet disc Not Published Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Wet multi-disc Seat Suspension & Adjustability Fully adjustable suspension seat with retractable seat belt Adjustable seat (standard) Front Axle Type Adjustable tubular steel, 2WD (M5660SUH); Cast iron bevel pinion drive with 55 degree turning angle, 4WD (M5660SUHD) Four-wheel drive (standard) Front Axle Rating 4410 lb at 55.9 in tread spacing (M5660SUH); 5290 lb at 55.9 in tread spacing (M5660SUHD) Not Published Drawbar Capacity 2200 lb 1653 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 138.7 in (M5660SUH); 136 in (M5660SUHD) 125.5 in Overall Width 73.2 in 70.3 in Wheelbase 82 in (M5660SUH); 80.7 in (M5660SUHD) 71.2 in Ground Clearance 16.3 in 15.3 in Min. Turn Radius without Brakes 10.8 ft (M5660SUH); 12.8 ft (M5660SUHD) 103.5 in (with brake applied) Height to Top of ROPS 95.3 in 97.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 4189 lb (M5660SUH); 4387 lb (M5660SUHD) 3745 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 6.5-16 (M5660SUH); 8.3-24 (M5660SUHD) 8-16 R1 Agricultural - Rear 14.9-28 13.6-24 R3 Turf - Front 29x12.50-15 29x12.5-15 R3 Turf - Rear 21.5L-16.1 44x18.0-20 R4 Industrial - Front 12.5/80-18 (M5660SUHD) 10-16.5 R4 Industrial - Rear 16.9-24 (M5660SUHD) 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1154SU: 2-lever quick attach coupler standard Front-end loader with standard quick attach mounting system Loader Model LA1154SU (also printed LA1154) FL9 Loader Lift Height LA1154: 130.9 in (height position); 115.7 in (power position) 103.2 in Loader Lift Capacity (Full Height) LA1154: 2469 lb (height position); 2928 lb (power position) 1795 lb Loader Breakout Force LA1154SU: 4230 lbf (height position); 5354 lbf (power position) 4136 lbf ▶ WarrantyWarranty Length & Coverage All usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. 24 months or 1500 hours (whichever occurs first); powertrain 48 months (consumer use) or 36 months / 2000 hours (business use) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
