▶ EngineEngine Manufacturer Kubota John Deere Engine Model V2403-CR-TE4 John Deere PowerTech 3029 Engine Type 4-cylinder, turbocharged, common-rail diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 148.5 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 58.7 hp 59 hp PTO Power 50 hp 41 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, pressurized radiator with recovery tank Liquid-cooled Air Cleaner Dry paper dual element, 8 in diameter, pre-cleaner standard Dry type, dual element (primary and secondary) Fuel System Common rail direct injection Not Published Alternator 45 A 40 A ▶ HydraulicsPump Type Gear pump Not Published Implement Flow 10.6 gpm 11.4 gpm Steering Flow 6.1 gpm 6.8 gpm Total Hydraulic Flow 16.5 gpm 18.2 gpm Overall Hydraulic Pump Flow 16.5 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (SCD) 1 No. of Optional Remote Valves 2 optional (3 maximum) 2 ▶ Fluid CapacityFuel Tank Capacity 17.2 gal OOS: 19.6 gal; Cab: 21.6 gal Coolant Capacity 8.5 qt 10 qt Crankcase Capacity 7.6 qt 9 qt Transmission / Hydraulic System Capacity 50.7 qt 10.3 gal Front Axle Fluid Capacity No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal ▶ PTO & HitchPTO Type Hydraulic, independent PTO, self-modulating multi-plate wet clutch with brake Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) PTO Rear 540 rpm (540/540E optional) 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II, convertible to I Hitch Lift Capacity 4,189 lb Not Published Hitch Lift Capacity (at 24”) 3,307 lb 3,192 lb Lift Control Type Position control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R SyncShuttle (standard); PowrReverser (optional) No. of Speeds 8F/8R 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 18.2 mph Not Published Max Travel Speed (Reverse) 18.6 mph Not Published Clutch Multiple wet disc Dry (SyncShuttle); wet (12F/12R PowrReverser) Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Differential lock, standard; pedal-operated, mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Mechanical wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Fully adjustable suspension seat with retractable seat belt Not Published Front Axle Type M5660SUH: adjustable tubular-steel 2WD axle; M5660SUHD: cast-iron bevel-pinion drive, 55-degree turning angle, 4WD 2WD or MFWD Front Axle Rating 4,410 lb at 55.9 in tread spacing (M5660SUH); 5,290 lb at 55.9 in tread spacing (M5660SUHD) Not Published Drawbar Capacity 3,300 lb (maximum tongue weight) 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 72.8 in 57.3 in Wheelbase 82 in (M5660SUH); 80.7 in (M5660SUHD) 80.7 in Ground Clearance 16.3 in 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 11.1 ft (M5660SUH); 12.8 ft (M5660SUHD) 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS 95.3 in 96.4 in Height to Top of ROPS (folded) Not Published 77.1 in Height to Top of Cab Model Not Published 94.3 in Overall Length 138.7 in (M5660SUH); 136 in (M5660SUHD) 137.8 in ▶ WeightTractor Weight (Base) 4,189 lb (M5660SUH); 4,387 lb (M5660SUHD) 2WD: 4,524 lb; MFWD: 5,511 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 Not Published R1 Agricultural - Front 9.5L-15 (M5660SUH); 9.5-22 (M5660SUHD) MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial R1 Agricultural - Rear 14.9-28 14.9-28 R3 Turf - Front 29x12.50-15 9.5-16 R3 Turf - Rear 21.5L-16.1 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front 12.5/80-18 (M5660SUHD) 12.5/80-18 R4 Industrial - Rear 16.9-24 (M5660SUHD) 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1154SU: 2-lever quick attach coupler standard 520M; H240 (NSL or MSL) Loader Model LA1154SU H240NSL Loader Lift Height LA1154SU: 130.9 in (height position); 115.7 in (power position) 131 in Loader Lift Capacity (Full Height) LA1154SU: 2,469 lb (height position); 2,928 lb (power position) 3,671 lb (H240NSL, at pivot) Loader Breakout Force LA1154SU: 4,230 lbf (height position); 5,354 lbf (power position) 4,504 lb (H240NSL, at pivot) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage Not Published
