▶ EngineEngine Manufacturer Kubota Kubota Engine Model F2803-EA V3307-DI Engine Type Vertical, water-cooled, 4-cycle diesel, 5-cylinder 4-cylinder inline, direct injected diesel No. of Cylinders 5 4 Displacement 167.6 in³ 203 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 61.6 hp Not Published PTO Power 52 hp 62 hp Engine Emissions Constraints Not Published Tier 2 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Primary element and secondary (safety) element 8 in dry, dual element Fuel System Indirect injection Direct injection Alternator Not Published ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11 gpm 11.0 gpm Steering Flow Not Published 6.1 gpm Total Hydraulic Flow Not Published 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow Not Published 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity ROPS: 17.2 gal; Cab: 25.1 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 7.7 qt 8.5 qt Crankcase Capacity 8.5 qt 11.6 qt Transmission / Hydraulic System Capacity ROPS: 42.3 qt; Cab: 45.4 qt 59.2 qt Front Axle Fluid Capacity Not Published Front differential case: 5.8 qt; front axle gear case: 3.7 qt ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category I and II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 3,307 lb 3,307 lb Lift Control Type Position, draft and mix control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 8 forward and 8 reverse, fully synchronized main shift Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 8F/8R 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) Not Published 18.5 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Not Published Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS (canopy optional); Ultra Grand Cab optional Steering Power steering Hydrostatic power steering Brakes Wet disc Mechanically operated wet disc brakes Seat Suspension & Adjustability Not Published Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Not Published 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 72.8 in (minimum) 73.2 in Wheelbase ROPS: 78.7 in; Cab: 81.7 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance Not Published 16.3 in Min. Turn Radius without Brakes Not Published 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 93.5 in 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.0 in 100.2 in Overall Length 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 2WD ROPS: 3,858 lb; 4WD ROPS: 4,078 lb 2WD: 4,475 lb; 4WD: 4,608 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 7.5-16 front; 4WD: 9.5-22 front; 16.9-28 rear Standard: 7.5-16 (2WD) or 9.5-24 (4WD) front, 16.9-30 rear R1 Agricultural - Front 2WD: 7.50-16; 4WD: 9.5-22 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 16.9-28 16.9-30 R3 Turf - Front Not Published 29x12.5-15 or 27x9.5-15 R3 Turf - Rear Not Published 18.4-26 or 21.5L-16.1 R4 Industrial - Front Not Published 14-17.5L (4WD) R4 Industrial - Rear Not Published 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1153: two-lever quick coupler Loader Model LA1002 LA1153 Loader Lift Height LA1002: 115.6 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) LA1002: 2,579 lb (at pivot pin) Not Published Loader Breakout Force LA1002: 3,330 lbf Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
