▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3800-TI-CRS V3800CR-TIEF4 Engine Type 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 4 4 Displacement 230 in³ 230 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 114.1 hp 105.6 hp PTO Power 92 hp 89 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, pressurized radiator, recovery tank Liquid-cooled Air Cleaner 8 in dry, dual element Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common rail direct injection Common rail direct injection Alternator 130 A, 12 V 60 A ▶ HydraulicsPump Type Gear pumps Gear pump Implement Flow 18.7 gpm 15.7 gpm Steering Flow 16.0 gpm 5.4 gpm Total Hydraulic Flow 34.7 gpm (18.7 + 16.0, computed) 21.3 gpm Overall Hydraulic Pump Flow Not Published 21.3 gpm Hydraulic System Type Pressure compensated, fixed displacement Open center Rear Remote Hydraulic Flow 18.7 gpm 15.7 gpm No. of Standard Remote Valves 2 (with built-in flow control) 2 (max 3) No. of Optional Remote Valves 3rd and 4th optional (4 max) 1 (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 50.2 gal 27.7 gal Coolant Capacity 11.3 qt 11 qt Crankcase Capacity 11.3 qt 11.3 qt Transmission / Hydraulic System Capacity 17.2 gal 63.4 qt Front Axle Fluid Capacity 7.2 qt (differential) plus 3.8 qt per bevel gear case 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540/1000 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,598 lb 7,055 lb (8,600 lb optional) Hitch Lift Capacity (at 24”) 6,834 lb (optional 9,447 lb) 5,181 lb Lift Control Type Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 24F/24R (32F/32R with optional creep) 8 forward, 8 reverse Max Travel Speed (Forward) 23.4 mph 18.6 mph Max Travel Speed (Reverse) 22.33 mph (with 18.4R38 tires, at rated rpm) 18.4 mph Clutch Multiple wet disc, electro-hydraulically operated, 5.2 in Multiple wet disc Differential Lock & Limited Slip Options Electro-hydraulic front differential lock; rear differential lock standard Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Certified ROPS cab standard Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Hydraulic wet disc Seat Suspension & Adjustability Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating 6,610 lb at 62.2 in tread (9,700 lb with loader) 5,730 lb Drawbar Capacity Not Published 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width 82.7 in 79.1 in Wheelbase 95.9 in 88.6 in Ground Clearance 19.5 in (crop clearance) 17.7 in (drawbar bracket) Min. Turn Radius without Brakes 13.1 ft (with Bi-Speed turn, 4WD on) 13.8 ft Height to Top of ROPS Not Published 99.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.8 in Not Applicable Overall Length 165.4 in 155.9 in ▶ WeightTractor Weight (Base) 9,788 lb (with standard tire) 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 13.6 R24 12.4-24 R1 Agricultural - Rear 18.4 R34 18.4-30 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front Not Published 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear Not Published 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model LA1955 LA1854 Loader Lift Height LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin LA1854: 5,501 lbf (height position); 6,470 lbf (power position) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
