▶ EngineEngine Manufacturer Kubota Fiat Powertrain Technologies (FPT) Engine Model V3800-TI-CRS F36 Engine Type 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel 4-cylinder diesel, turbocharged and aftercooled No. of Cylinders 4 4 Displacement 230 in³ 220 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 114.1 hp 115.3 hp PTO Power 92 hp Not Published Engine Emissions Constraints Tier 4 Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR Cooling System Type Liquid-cooled, pressurized radiator, recovery tank Not Published Air Cleaner 8 in dry, dual element Not Published Fuel System Common rail direct injection Common rail fuel injection Alternator 130 A, 12 V Not Published ▶ HydraulicsPump Type Gear pumps Open center, dual pumps: implement pump plus dedicated steering pump Implement Flow 18.7 gpm 21.7 gpm Steering Flow 16.0 gpm 9.7 gpm Total Hydraulic Flow 34.7 gpm (18.7 + 16.0, computed) 31.4 gpm (21.7 + 9.7, computed) Overall Hydraulic Pump Flow Not Published 31.4 gpm (21.7 + 9.7, computed) Hydraulic System Type Pressure compensated, fixed displacement Open center Rear Remote Hydraulic Flow 18.7 gpm Not Published No. of Standard Remote Valves 2 (with built-in flow control) 2 rear remotes (four couplers) No. of Optional Remote Valves 3rd and 4th optional (4 max) 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) ▶ Fluid CapacityFuel Tank Capacity 50.2 gal 34.3 gal Coolant Capacity 11.3 qt Not Published Crankcase Capacity 11.3 qt Not Published Transmission / Hydraulic System Capacity 17.2 gal Not Published Front Axle Fluid Capacity 7.2 qt (differential) plus 3.8 qt per bevel gear case Not Published ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Fully-independent, electrohydraulic, wet-clutch PTO Rear 540/1000 rpm 540/1000 rpm (standard, interchangeable) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,598 lb Not Published Hitch Lift Capacity (at 24”) 6,834 lb (optional 9,447 lb) 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) Lift Control Type Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard 12x12: mechanical draft control; Dual Command: electronic draft control ▶ Transmission & DrivetrainTransmission Type 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle No. of Speeds 24F/24R (32F/32R with optional creep) 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) Max Travel Speed (Forward) 23.4 mph 25 mph Max Travel Speed (Reverse) 22.33 mph (with 18.4R38 tires, at rated rpm) Not Published Clutch Multiple wet disc, electro-hydraulically operated, 5.2 in Not Published Differential Lock & Limited Slip Options Electro-hydraulic front differential lock; rear differential lock standard Electrohydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Certified ROPS cab standard Not Published Steering Hydrostatic power steering Not Published Brakes Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Not Published Seat Suspension & Adjustability Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt Air-suspension cloth seat Front Axle Type 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock 4WD heavy-duty, class 1.5 front axle (standard) Front Axle Rating 6,610 lb at 62.2 in tread (9,700 lb with loader) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 82.7 in 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) Wheelbase 95.9 in 92.5 in Ground Clearance 19.5 in (crop clearance) Not Published Min. Turn Radius without Brakes 13.1 ft (with Bi-Speed turn, 4WD on) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.8 in 103.6 in Overall Length 165.4 in 158.2 in ▶ WeightTractor Weight (Base) 9,788 lb (with standard tire) 10,240 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available R1 Agricultural - Front 13.6 R24 Not Published R1 Agricultural - Rear 18.4 R34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) Loader Model LA1955 650LU (NSL); 655LU (MSL) Loader Lift Height LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) Loader Lift Capacity (Full Height) LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) Loader Breakout Force LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
