▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V3307-DI L3C19-T Engine Type 4-cylinder inline, direct injected diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 4 3 Displacement 203 in³ 116 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) Not Published 55 hp PTO Power 55 hp 44 hp Engine Emissions Constraints Tier 2 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner 8 in dry, dual element Replaceable dry element Fuel System Direct injection Common rail direct injection Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V 70 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.0 gpm 8.2 gpm Steering Flow 6.1 gpm 5.3 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) Not Published Overall Hydraulic Pump Flow 17 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2nd and 3rd optional 2 ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal 10.5 gal Coolant Capacity 8.5 qt Not Published Crankcase Capacity 11.6 qt Not Published Transmission / Hydraulic System Capacity 10.6 gal Not Published Front Axle Fluid Capacity 8.5 qt Not Published ▶ PTO & HitchPTO Type Live independent PTO, hydraulically operated wet clutch with PTO brake Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category II Category I Hitch Lift Capacity 4189 lb 2,756 lb Hitch Lift Capacity (at 24”) 3307 lb 2,469 lb Lift Control Type Position, draft (top link sensing) and mix control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models 3-range hydrostatic (HST) No. of Speeds 8F/8R (12F/12R with optional creep) infinitely variable, 3 ranges Max Travel Speed (Forward) 18 mph 17.9 mph Max Travel Speed (Reverse) 18.0 mph Not Published Clutch Dry single plate (synchro shuttle) / multiple wet disks (hydraulic shuttle) Not Applicable Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Not Published Steering Hydrostatic power steering Power steering Brakes Multiple wet disc, mechanical Wet multi-disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore and aft, arm rests) with retractable seat belt; optional air ride seat suspension (cab) Adjustable suspension seat Front Axle Type 4WD: Bevel gear type with Easy-To-Shift 4WD engagement while rolling Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity 2200 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 140.4 in; 4WD: 135.6 in 128.1 in Overall Width 73.2 in 69.1 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 73.2 in Ground Clearance 15.4 in Not Published Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft Not Published Height to Top of ROPS 96.9 in 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model 99.8 in 93.3 in ▶ WeightTractor Weight (Base) 2WD ROPS: 4650 lb; 4WD ROPS: 4785 lb 3,770 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 2WD: 7.50-16; 4WD: 9.5-24 9.5-16 R1 Agricultural - Rear 16.9-28 13.6-24 R3 Turf - Front 2WD: 29x12.5-15 or 27x9.5-15 28x8.50-15 R3 Turf - Rear 2WD: 21.5L-16.1 or 16.9-24 41x14.00-20 R4 Industrial - Front 12.5/80-18 (4WD) 12-16.5 R4 Industrial - Rear 16.9-24 (4WD) 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler Quick-Attach faceplate; quick-connect loader mounting (L360A) Loader Model LA1153 L360A Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in 112 in Loader Lift Capacity (Full Height) Not Published 2,500 lb Loader Breakout Force Not Published 3,114 lbf ▶ WarrantyWarranty Length & Coverage Not Published 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain
