▶ EngineEngine Manufacturer Kubota KIOTI (Daedong) Engine Model V3307-DI 3F183T Engine Type 4-cylinder inline, direct injected diesel KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 4 3 Displacement 203 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) Not Published 55 hp PTO Power 55 hp 43.1 hp Engine Emissions Constraints Tier 2 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner 8 in dry, dual element Dry type element Fuel System Direct injection Common Rail Direct Injection (CRDI) Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 11.0 gpm 9.6 gpm Steering Flow 6.1 gpm 8.2 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) 17.9 gpm Overall Hydraulic Pump Flow 17 gpm 17.9 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2nd and 3rd optional 1 ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal 14.8 gal Coolant Capacity 8.5 qt 2.0 gal Crankcase Capacity 11.6 qt 1.58 gal Transmission / Hydraulic System Capacity 10.6 gal 11.89 gal Front Axle Fluid Capacity 8.5 qt 1.8 gal ▶ PTO & HitchPTO Type Live independent PTO, hydraulically operated wet clutch with PTO brake Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category II Category I & II Hitch Lift Capacity 4189 lb 3,538 lb Hitch Lift Capacity (at 24”) 3307 lb 3,177 lb Lift Control Type Position, draft (top link sensing) and mix control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Hydrostatic No. of Speeds 8F/8R (12F/12R with optional creep) 3 Range Max Travel Speed (Forward) 18 mph 18.26 mph Max Travel Speed (Reverse) 18.0 mph 18.26 mph Clutch Dry single plate (synchro shuttle) / multiple wet disks (hydraulic shuttle) Not Published Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Multiple wet disc, mechanical Wet Multi Disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore and aft, arm rests) with retractable seat belt; optional air ride seat suspension (cab) Adjustable Seat Front Axle Type 4WD: Bevel gear type with Easy-To-Shift 4WD engagement while rolling Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 2200 lb 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 140.4 in; 4WD: 135.6 in 139.6 in Overall Width 73.2 in 65.7 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 75.6 in Ground Clearance 15.4 in 15.7 in Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 10.0 ft Height to Top of ROPS 96.9 in 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.8 in Not Published ▶ WeightTractor Weight (Base) 2WD ROPS: 4650 lb; 4WD ROPS: 4785 lb 4,198 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 2WD: 7.50-16; 4WD: 9.5-24 9.5-16 R1 Agricultural - Rear 16.9-28 16.9-24 R3 Turf - Front 2WD: 29x12.5-15 or 27x9.5-15 29-12.5-15 R3 Turf - Rear 2WD: 21.5L-16.1 or 16.9-24 21.5L-16.1 R4 Industrial - Front 12.5/80-18 (4WD) 10-16.5 R4 Industrial - Rear 16.9-24 (4WD) 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model LA1153 KL6010 Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) Not Published KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force Not Published KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
