▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-DI V2403-CR-TE4-GL2 Engine Type 4-cylinder inline, direct injected diesel Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 203 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) Not Published 56 hp PTO Power 55 hp 46.5 hp Engine Emissions Constraints Tier 2 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner 8 in dry, dual element Dry paper, dual element Fuel System Direct injection Electronic Common Rail System (CRS) Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 11.0 gpm 9.4 gpm Steering Flow 6.1 gpm 4.7 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) 14.1 gpm Overall Hydraulic Pump Flow 17 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2nd and 3rd optional Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal 13.5 gal Coolant Capacity 8.5 qt 8.7 qt Crankcase Capacity 11.6 qt 9.9 qt Transmission / Hydraulic System Capacity 10.6 gal 11.9 gal Front Axle Fluid Capacity 8.5 qt 8.9 qt ▶ PTO & HitchPTO Type Live independent PTO, hydraulically operated wet clutch with PTO brake Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category II SAE Category I & II Hitch Lift Capacity 4189 lb 3,858 lb Hitch Lift Capacity (at 24”) 3307 lb 2,976 lb Lift Control Type Position, draft (top link sensing) and mix control Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Hydrostatic transmission No. of Speeds 8F/8R (12F/12R with optional creep) 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 18 mph 16.8 mph Max Travel Speed (Reverse) 18.0 mph 15.2 mph Clutch Dry single plate (synchro shuttle) / multiple wet disks (hydraulic shuttle) Not Published Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Multiple wet disc, mechanical Wet disc type, mechanically activated Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore and aft, arm rests) with retractable seat belt; optional air ride seat suspension (cab) Suspension seat with fore/aft travel adjustment, suspension adjust knob, backrest tilt adjustment, swivel and arm rest Front Axle Type 4WD: Bevel gear type with Easy-To-Shift 4WD engagement while rolling 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 2200 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 140.4 in; 4WD: 135.6 in 135.0 in Overall Width 73.2 in 67.3 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 75.4 in Ground Clearance 15.4 in 15.4 in Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 9.2 ft (with brake applied) Height to Top of ROPS 96.9 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.8 in Not Applicable ▶ WeightTractor Weight (Base) 2WD ROPS: 4650 lb; 4WD ROPS: 4785 lb 3,990 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 2WD: 7.50-16; 4WD: 9.5-24 9.5-16 R1 Agricultural - Rear 16.9-28 14.9-26; 13.6-28 R3 Turf - Front 2WD: 29x12.5-15 or 27x9.5-15 29X12.50-15 R3 Turf - Rear 2WD: 21.5L-16.1 or 16.9-24 44X18-20 R4 Industrial - Front 12.5/80-18 (4WD) 10-16.5 R4 Industrial - Rear 16.9-24 (4WD) 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model LA1153 LA1055 Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in 112.7 in Loader Lift Capacity (Full Height) Not Published 2361 lb Loader Breakout Force Not Published 3171 lbf (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
