▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V3307-DI L3CRV-T7 Engine Type 4-cylinder inline, direct injected diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 3 Displacement 203 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) Not Published 55 hp PTO Power 55 hp Gear: 46.7 hp; HST: 44 hp Engine Emissions Constraints Tier 2 Tier 4B (final) Cooling System Type Liquid-cooled Liquid cooled Air Cleaner 8 in dry, dual element Replaceable primary and inner elements Fuel System Direct injection Electronically controlled common rail direct injection Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V ROPS: 70 A; Cab: 85 A ▶ HydraulicsPump Type Not Published Gear Implement Flow 11.0 gpm 8.2 gpm Steering Flow 6.1 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow 17.1 gpm (11.0 + 6.1, computed) Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2nd and 3rd optional Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 8.5 qt 2.3 gal Crankcase Capacity 11.6 qt 5.8 qt Transmission / Hydraulic System Capacity 59.2 qt 11.4 gal Front Axle Fluid Capacity Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side 2.2 gal ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity 4,189 lb 2,756 lb Hitch Lift Capacity (at 24”) 3,307 lb 2,116 lb Lift Control Type Position, draft (top link sensing) and mix control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 8F/8R (12F/12R with optional creep) Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) 17.8 mph Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) 18.0 mph Gear: 15.3 mph; HST: 11.37 mph Clutch Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Not Published Steering Hydrostatic power steering Power steering Brakes Multiple wet disc, mechanical Wet multi-disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type 4WD: bevel-gear type, on-the-go engagement Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity 2,200 lb Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Width 73.2 in 69.1 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 73.2 in Ground Clearance 15.4 in 15 in Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS 96.9 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.8 in 94 in Overall Length 2WD: 140.4 in; 4WD: 135.6 in 128.1 in ▶ WeightTractor Weight (Base) 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 2WD: 7.5-16; 4WD: 9.5-24 9.5-16 R1 Agricultural - Rear 16.9-28 13.6-24 R3 Turf - Front 2WD: 29x12.5-15 or 27x9.5-15 28x8.50-15 R3 Turf - Rear 2WD: 21.5L-16.1 or 16.9-24 41x14.00-20 R4 Industrial - Front 12.5/80-18 (4WD) 12x16.5 R4 Industrial - Rear 16.9-24 (4WD) 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler Tool-free loader mount; optional skid-steer quick-attach plates Loader Model LA1153 260TLA Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in 260TLA: 109 in (at pivot pin) Loader Lift Capacity (Full Height) Not Published 260TLA: 2,371 lb (at bucket pivot pin, max height) Loader Breakout Force Not Published 260TLA: 4,081 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
