▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-CR-TE4 V3307-CR-TE4 Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged Liquid-cooled, diesel, 4-cylinder No. of Cylinders 4 4 Displacement 203 in³ 203 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 66.4 hp 65.4 hp PTO Power 56 hp 52 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dual element (primary and secondary elements) Fuel System Common Rail System (CRS) Common Rail System (CRS) Alternator 45 A, 12 V 130 A ▶ HydraulicsPump Type Gear Not Published Implement Flow 11.0 gpm 16.7 gpm Steering Flow 6.1 gpm 6.3 gpm Total Hydraulic Flow 17.1 gpm 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) Overall Hydraulic Pump Flow 17.1 gpm 23.0 gpm (16.7 + 6.3, computed) Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 (SCD) 2 (SCD / FD) No. of Optional Remote Valves 2nd, 3rd (optional) Max. 3 ▶ Fluid CapacityFuel Tank Capacity 18.5 gal 23.8 gal Coolant Capacity 8.5 qt 10.6 qt Crankcase Capacity 12.7 qt 12.7 qt Transmission / Hydraulic System Capacity 14.8 gal 49.6 qt Front Axle Fluid Capacity 5.8 qt (differential) plus 3.7 qt (each bevel gear case) 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm (540/540E optional) 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I / II I / II Hitch Lift Capacity 4,189 lb 4,189 lb Hitch Lift Capacity (at 24”) 3,307 lb 3,307 lb Lift Control Type Position, Draft (Top Link Sensing) & Mixed Control Position, draft (top link sensing) & mixed control ▶ Transmission & DrivetrainTransmission Type Hydraulic-shuttle transmission (fully synchronized) Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) No. of Speeds F8/R8 F12/R12 (option: F18/R18 with creep) Max Travel Speed (Forward) 18.0 mph 24.9 mph Max Travel Speed (Reverse) 17.7 mph 24.7 mph Clutch Multiple wet disc Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Ultra Grand Cab II Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Hydraulic wet disc Seat Suspension & Adjustability Suspension seat, adjustable (travel, suspension tension, backrest tilt, armrests); optional air-suspension seat on cab models Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Front Axle Type Bevel gear type with 55 degree turning angle (4WD) Bevel gear type (4WD) Front Axle Rating 5,290 lb (6,615 lb with loader) Not Published Drawbar Capacity 2,200 lb 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 73.0 in 75.6 in Wheelbase 83.1 in 84.1 in Ground Clearance 18.1 in (crop clearance at front axle); 15.4 in (minimum ground clearance) 18.1 in (front axle crop clearance) Min. Turn Radius without Brakes 11.8 ft 11.8 ft Height to Top of ROPS 96.9 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) 101 in Overall Length 138 in 144 in ▶ WeightTractor Weight (Base) 5,005 lb 6,008 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 9.5-24 front, 16.9-28 rear Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 9.5-24 320/70R24 R1 Agricultural - Rear 16.9-28/14.9-28 420/75R34 R3 Turf - Front LSW305-521 9.50-24 R3 Turf - Rear LSW570-648 18.4-26 R4 Industrial - Front 12.5/80-18 14-17.5 R4 Industrial - Rear 16.9-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1154A: 2-Lever Quick Coupler LA1154A: 2-Lever Quick Coupler Loader Model LA1154A LA1154A Loader Lift Height Height position: 132.7 in; Power position: 117.2 in LA1154A: Height position: 133.0 in; Power position: 117.6 in Loader Lift Capacity (Full Height) Height position: 2,469 lb; Power position: 2,928 lb LA1154A: Height position: 2,674 lb; Power position: 2,928 lb Loader Breakout Force Height position: 4,230 lbf; Power position: 5,354 lbf LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
