Spec
KubotaM6060
KubotaM4D-071
PTO Power
56.0 hp (41.7 kW)
60 hp (44.7 kW)
Alternator
ROPS: 12 V, 45 A; CAB: 12 V, 60 A
12 V, 130 A
Air Cleaner
Not Published
Not Published
Engine Type
Liquid-cooled, diesel, 4-cylinder, Turbocharged
Liquid-cooled, diesel, 4-cylinder
Fuel System
Common Rail System (CRS)
Common Rail System (CRS)
Displacement
203.3 (3331)
203.3 (3331)
No. of Cylinders
4
4
Rated Engine Speed
2400 rpm
2400 rpm
Cooling System Type
Liquid-cooled
Liquid-cooled
Engine Manufacturer
Kubota
Kubota
Engine Emissions Constraints
Tier IV EPA emission regulations; CRS with EGR + DPF muffler
Not Published
Engine Power (Gross vs. Net HP)
Gross: 66.4 hp (49.5 kW)
Gross: 72.1 hp (53.7 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Gear
Gear
Steering Flow
23.1 L/min (6.1 gpm)
23.8 L/min (6.3 gpm)
Implement Flow
41.6 L/min (11.0 gpm)
63.2 L/min (16.7 gpm)
Total Hydraulic Flow
64.7 L/min (17.1 gpm)
87.0 L/min (23.0 gpm)
Hydraulic System Type
Open Center
Open Center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
64.7 L/min (17.1 gpm)
87.0 L/min (23.0 gpm)
No. of Optional Remote Valves
2nd, 3rd (optional)
Max. 3
No. of Standard Remote Valves
1 (SCD)
2 (SCD / FD)
R3 Turf - Rear
Not Published
Not Published
R3 Turf - Front
Not Published
Not Published
Tire Size & Options
Standard tire size
Standard tire size
R4 Industrial - Rear
Not Published
Not Published
R4 Industrial - Front
Not Published
Not Published
R1 Agricultural - Rear
16.9-28/14.9-28
420/75R34
R1 Agricultural - Front
HFC (2WD): 9.5L-15; HD/HDC (4WD): 9.5-24
320/70R24
PTO Rear
540 rpm (540/540E optional)
540/540E rpm
PTO Type
Live-independent PTO, electro-hydraulic clutch with brake
Live-independent PTO, electro-hydraulic clutch with brake
Lift Control Type
Position, Draft (Top Link Sensing) & Mixed Control
Position, draft (top link sensing) & mixed control
Hitch Lift Capacity
Not Published
Not Published
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
I / II
I / II
Hitch Lift Capacity (at 24”)
3307 lbs (1500 kg)
3307 lbs (1500 kg)
Rear 3-Point Hitch Lift Capacity
Not Published
Not Published
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
ROPS: 18.5 gal (70 L); CAB: 23.8 gal (90 L)
23.8 gal (90 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
Height position: 132.7 in (3370 mm); Power position: 117.2 in (2977 mm)
Height position: 133.0 in (3378 mm); Power position: 117.6 in (2987 mm)
Loader Breakout Force
Not Published
Not Published
Price for Backhoe Option
Not Applicable
Not Applicable
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
LA1154A: 2-Lever Quick Coupler
LA1154A: 2-Lever Quick Coupler
Loader Lift Capacity (Full Height)
Height position: 2469 lb (1120 kg); Power position: 2928 lb (1328 kg)
Height position: 2674 lb (1213 kg); Power position: 2928 lb (1328 kg)
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
