▶ EnginePTO Power — 19.2 (14.3) HP (kW) Alternator — 40 A Air Cleaner — Dual paper element Engine Type — E-TVCS, liquid cooled, 3-cylinder diesel Fuel System — Radial air flow Displacement — 68.5 (1123) cu. in. (cc) No. of Cylinders — 3 Rated Engine Speed — 2600 rpm Cooling System Type — Liquid Cooled Engine Manufacturer — Kubota Engine Power (Gross) — 21.9 (16.3) HP (kW) Engine Emissions Constraints — Tier 4 ▶ WeightTractor Weight (Base) — 1,404 lbs. Weight with ROPS and Loader — 1,521 lbs. ▶ WarrantyWarranty Length & Coverage — Full warranty: 2 years / 2,000 hours; Powertrain warranty: 6 years / 2,000 hours ▶ HydraulicsPump Type — Dual pump Steering Flow — 2.6 gpm 9.8 lpm Implement Flow — 4.0 gpm Total Hydraulic Flow — 7.0 (26.4) gpm (ℓ/min.) Hydraulic System Type — Open center System Operating Pressure — 2500 psi Rear Remote Hydraulic Flow — Front & Rear outlet Overall Hydraulic Pump Flow — 7.0 (26.4) gpm (ℓ/min.) No. of Optional Remote Valves — 1 No. of Standard Remote Valves — 0 ▶ PTO & HitchPTO Rear — 540, 1000 rpm PTO Type — Transmission driven with one way clutch Lift Control Type — Position control valve Hitch Lift Capacity — 1653 (750) lbs. (kg) Mid-PTO Availability — 2500 rpm Category, 3-Point Hitch — Category I Hitch Lift Capacity (at 24”) — 1808 (820) lbs. (kg); 1411 (640) lbs. (kg); 1290 (585) lbs. (kg) ▶ Tire OptionsR3 Turf - Rear — 33x12.5-15 R3 Turf - Front — 23x8.50-12 R1 Agricultural - Rear — 9.5-16 R1 Agricultural - Front — 6-12 ▶ Fluid CapacityCoolant Capacity — 4.0 (3.8) qts. (ℓ) Crankcase Capacity — 3.3 (3.1) qts. (ℓ) Fuel Tank Capacity — 6.1 gal. Transmission / Hydraulic System Capacity — 3.3 (12.5) gal (ℓ) ▶ Loader & AttachmentsLoader Lift Height — 78.5" Loader Breakout Force — 2,146 lbf. Quick Attach Loader System — LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Loader Lift Capacity (Full Height) — 1,175 lbs. ▶ Transmission & DrivetrainClutch — Dry single plate No. of Speeds — 9 Forward, 3 Reverse Transmission Type — Gear (9 Forward, 3 Reverse) Max Travel Speed (Forward) — 0-11.7 (0-18.8) mph (km/h) Max Travel Speed (Reverse) — 0-6.0 (0-9.6) mph (km/h) Differential Lock & Limited Slip Options — Standard ▶ Chassis, Steering & ControlsBrakes — Multi-plate wet disc Steering — Integral type power steering Front Axle Type — Cast-iron front axle Drawbar Capacity — 661.4 lb (660 lbs) Seat Suspension & Adjustability — High-back seat (absorbs shock); NOTE: Deluxe seat with armrests and seat suspension listed for HST models only - not explicitly confirmed for B2401 gear-drive (DT) in spec sheet ▶ Dimensions & ManeuverabilityWheelbase — 61.4 (1560) in. (mm) Overall Width — 44.3 (1125) in. (mm) Overall Length — 93.9 in / 93.9 in Ground Clearance — 12.0 (305) in. (mm) Height to Top of ROPS — 83.9 in. Min. Turn Radius without Brakes — 6.9 (2.1) feet (m) Overall Length with 3-Point Hitch — 93.9 in. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
