▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-DI V3307-CR-TE4 Engine Type 4-cylinder inline, direct injected diesel Liquid-cooled, diesel, 4-cylinder No. of Cylinders 4 4 Displacement 203 in³ 203 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) Not Published 65.4 hp PTO Power 62 hp 52 hp Engine Emissions Constraints Tier 2 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner 8 in dry, dual element Dual element (primary and secondary elements) Fuel System Direct injection Common Rail System (CRS) Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V 130 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.0 gpm 16.7 gpm Steering Flow 6.1 gpm 6.3 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) Overall Hydraulic Pump Flow 17.1 gpm (11.0 + 6.1, computed) 23.0 gpm (16.7 + 6.3, computed) Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 2 (SCD / FD) No. of Optional Remote Valves 2nd and 3rd optional Max. 3 ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal 23.8 gal Coolant Capacity 8.5 qt 10.6 qt Crankcase Capacity 11.6 qt 12.7 qt Transmission / Hydraulic System Capacity 59.2 qt 49.6 qt Front Axle Fluid Capacity Front differential case: 5.8 qt; front axle gear case: 3.7 qt 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II I / II Hitch Lift Capacity 4,189 lb 4,189 lb Hitch Lift Capacity (at 24”) 3,307 lb 3,307 lb Lift Control Type Position, draft (top link sensing) and mix control Position, draft (top link sensing) & mixed control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) No. of Speeds 8F/8R (12F/12R with optional creep) F12/R12 (option: F18/R18 with creep) Max Travel Speed (Forward) 18.5 mph 24.9 mph Max Travel Speed (Reverse) Not Published 24.7 mph Clutch Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (canopy optional); Ultra Grand Cab optional Ultra Grand Cab II Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanically operated wet disc brakes Hydraulic wet disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Front Axle Type 4WD: bevel-gear type, on-the-go engagement Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 2,200 lb 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 73.2 in 75.6 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 84.1 in Ground Clearance 16.3 in 18.1 in (front axle crop clearance) Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 11.8 ft Height to Top of ROPS 97.2 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in 101 in Overall Length 2WD: 140.4 in; 4WD: 135.6 in 144 in ▶ WeightTractor Weight (Base) 2WD: 4,475 lb; 4WD: 4,608 lb 6,008 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.5-16 (2WD) or 9.5-24 (4WD) front, 16.9-30 rear Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 2WD: 7.5-16; 4WD: 9.5-24 320/70R24 R1 Agricultural - Rear 16.9-30 420/75R34 R3 Turf - Front 29x12.5-15 or 27x9.5-15 9.50-24 R3 Turf - Rear 18.4-26 or 21.5L-16.1 18.4-26 R4 Industrial - Front 14-17.5L (4WD) 14-17.5 R4 Industrial - Rear 16.9-24 (4WD) 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler LA1154A: 2-Lever Quick Coupler Loader Model LA1153 LA1154A Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in LA1154A: Height position: 133.0 in; Power position: 117.6 in Loader Lift Capacity (Full Height) Not Published LA1154A: Height position: 2,674 lb; Power position: 2,928 lb Loader Breakout Force Not Published LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
