▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V3307-DI L4C25-T Engine Type 4-cylinder inline, direct injected diesel In-line vertical, water cooled 4-cycle diesel, CRDI No. of Cylinders 4 4 Displacement 203 in³ 152.85 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) Not Published 63 hp PTO Power 62 hp 54.1 hp Engine Emissions Constraints Tier 2 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner 8 in dry, dual element Dry Fuel System Direct injection Delphi, CRDI Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear type, engine drive Implement Flow 11.0 gpm 14.5 gpm Steering Flow 6.1 gpm 6.6 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) 21.1 gpm Overall Hydraulic Pump Flow 17.2 gpm 21.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 2 Pairs (Front), 2 Pairs (Rear) No. of Optional Remote Valves 2nd and 3rd optional Not Published ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal 24.3 gal Coolant Capacity 8.5 qt 3.0 gal Crankcase Capacity 11.6 qt 1.8 gal Transmission / Hydraulic System Capacity 10.6 gal 16.5 gal Front Axle Fluid Capacity 8.5 qt 2.3 gal ▶ PTO & HitchPTO Type Live independent PTO, hydraulically operated wet clutch with PTO brake Independent PTO Rear 540 rpm 540 / 540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 4189 lb 4,079 lb Hitch Lift Capacity (at 24”) 3307 lb 3,483 lb Lift Control Type Position, draft (top link sensing) and mix control Position & Draft ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Synchro Shuttle No. of Speeds 8F/8R (12F/12R with optional creep) F16 x R16 Max Travel Speed (Forward) 18.7 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate (synchro shuttle) / multiple wet disks (hydraulic shuttle) Dry single clutch Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (canopy optional); Ultra Grand Cab optional Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Mechanically operated wet disc brakes Wet, Multi-disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore and aft, arm rests) with retractable seat belt; optional air ride seat suspension (cab) Seat With Suspension & Armrest Front Axle Type 4WD: Bevel gear type with Easy-To-Shift 4WD engagement while rolling Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 2200 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 140.4 in; 4WD: 135.6 in 140 in Overall Width 73.2 in 72.6 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 83.1 in Ground Clearance 16.3 in Not Published Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 12.8 ft (3.9 m) Height to Top of ROPS 97.2 in 113.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in Not Published ▶ WeightTractor Weight (Base) 2WD ROPS: 4675 lb; 4WD ROPS: 4805 lb 5,313 lb Weight with ROPS and Loader Not Published 6,503 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.5-16 (2WD) or 9.5-24 (4WD) front, 16.9-30 rear Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D R1 Agricultural - Front 2WD: 7.5-16; 4WD: 9.5-24 9.5-24 (Standard Ag); 11.2-24 (Large Ag) R1 Agricultural - Rear 16.9-30 16.9-28 (Standard Ag); 16.9-30 (Large Ag) R3 Turf - Front 29x12.5-15 or 27x9.5-15 Not Published R3 Turf - Rear 18.4-26 or 21.5L-16.1 Not Published R4 Industrial - Front 14-17.5L (4WD) 10.5/80x18 10PR R4 Industrial - Rear 16.9-24 (4WD) 19.5Lx24 8PR ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) Loader Model LA1153 LL5001 Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in LL5001: 132.9 in (height position); 116.8 in (power position) Loader Lift Capacity (Full Height) Not Published LL5001: 3,426 lb (height position); 3,488 lb (power position) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
