▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-CR-TE4 V3307-CR-TE4 Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 203 in³ 203 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 72.1 hp 72.1 hp PTO Power 62 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common Rail System (CRS) Common Rail System (CRS) Alternator 60 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 11.0 gpm 16.2 gpm Steering Flow 6.1 gpm 6.1 gpm Total Hydraulic Flow 17.1 gpm 22.3 gpm Overall Hydraulic Pump Flow 17.1 gpm 22.3 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow 11.0 gpm 16.2 gpm No. of Standard Remote Valves 1 (SCD) 1 (SCD) No. of Optional Remote Valves 2nd, 3rd (optional) 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 18.5 gal Coolant Capacity 8.5 qt 8.5 qt Crankcase Capacity 12.7 qt 12.7 qt Transmission / Hydraulic System Capacity 14.8 gal 14.8 gal Front Axle Fluid Capacity 5.8 qt (differential) plus 3.7 qt (each bevel gear case) 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm (540/540E optional) 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I / II I / II Hitch Lift Capacity 4189 lb 4189 lb Hitch Lift Capacity (at 24”) 3307 lb 3307 lb Lift Control Type Position, Draft (Top Link Sensing) & Mixed Control Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Hydraulic-shuttle (F8/R8), fully synchronized (4-speed main) Hydraulic-shuttle (F12/R12), fully synchronized (6-speed main) No. of Speeds F8/R8 F12/R12 Max Travel Speed (Forward) 18.8 mph 24.3 mph Max Travel Speed (Reverse) 18.5 mph 23.9 mph Clutch Multiple wet disc Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Limited slip differential (front); mechanical differential lock (rear) ▶ Chassis, Steering & ControlsFrame Type Certified ROPS cab Two-post foldable ROPS Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Hydraulic wet disc Seat Suspension & Adjustability Fully adjustable suspension seat (travel, suspension tension, backrest tilt, arm rests); optional air ride seat on cab models Fully adjustable suspension seat (travel, suspension tension, backrest tilt, arm rests); optional air ride seat on cab models Front Axle Type Bevel gear type with 55 degree turning angle (4WD) Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating 5290 lb (6615 lb with loader) 5290 lb (6615 lb with loader) Drawbar Capacity 2200 lb 2200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 138.0 in 138.0 in Overall Width 73.0 in 73.0 in Wheelbase 83.1 in 83.1 in Ground Clearance 18.1 in 18.1 in Min. Turn Radius without Brakes 11.8 ft 11.8 ft Height to Top of ROPS Not Published 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101.0 in Not Published ▶ WeightTractor Weight (Base) 5380 lb 5027 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 9.5-24 front, 16.9-30 rear Standard: 9.5-24 front, 16.9-30 rear R1 Agricultural - Front 9.5-24 9.5-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front 9.5-24 or LSW305-521 Not Published R3 Turf - Rear 18.4-26 or LSW570-648 Not Published R4 Industrial - Front 14-17.5 14-17.5 R4 Industrial - Rear 16.9-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1154A: 2-Lever Quick Coupler LA1154A: 2-Lever Quick Coupler Loader Model LA1154A LA1154A Loader Lift Height Height position: 132.7 in; Power position: 117.2 in Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) Height position: 2469 lb; Power position: 2928 lb Height position: 2469 lb; Power position: 2928 lb Loader Breakout Force Height position: 4230 lbf; Power position: 5354 lbf Height position: 4230 lbf; Power position: 5354 lbf ▶ WarrantyWarranty Length & Coverage All Usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. All Usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. ▶ ITC Company AccessoriesAccessories that fit
