▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V2403CR-T L3C19-T Engine Type Common rail direct injection, liquid-cooled, turbocharged 4-cylinder diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 4 3 Displacement 148.6 in³ 116 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 54.7 hp 55 hp PTO Power F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry, dual element Replaceable dry element Fuel System Common rail direct injection Common rail direct injection Alternator 45 A 70 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.5 gpm 8.2 gpm Steering Flow 4.9 gpm 5.3 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 (optional) 2 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 10.5 gal Coolant Capacity 6.9 qt Not Published Crankcase Capacity 9.9 qt Not Published Transmission / Hydraulic System Capacity 11.6 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent hydraulic PTO with PTO brake, wet clutch Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity Not Published 2,756 lb Hitch Lift Capacity (at 24”) 2310 lb 2,469 lb Lift Control Type Position control standard, draft control optional Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th, 2-range); HST (4WD): Hydrostatic transmission, 3-range 3-range hydrostatic (HST) No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range infinitely variable, 3 ranges Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph 17.9 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph Not Published Clutch F (2WD gear), DT (4WD gear): Dry single plate; HST (4WD): No clutch Not Applicable Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Not Published Steering Hydrostatic power steering Power steering Brakes Mechanical wet disc Wet multi-disc Seat Suspension & Adjustability High-back suspension seat Adjustable suspension seat Front Axle Type 4WD: Bevel gear type Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity 1650 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (w/o 3P) (without 3-point hitch) 128.1 in Overall Width 69.7 in 69.1 in Wheelbase 74.6 in 73.2 in Ground Clearance F (2WD gear): 15.9 in; DT (4WD gear), HST (4WD): 15.2 in Not Published Min. Turn Radius without Brakes F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (w/brake) (with brake applied) Not Published Height to Top of ROPS 95.7 in 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published 93.3 in ▶ WeightTractor Weight (Base) F (2WD gear): 3474 lb; DT (4WD gear): 3716 lb; HST (4WD): 3734 lb 3,770 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-26 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1065: 2-lever quick coupler standard Quick-Attach faceplate; quick-connect loader mounting (L360A) Loader Model LA1065 L360A Loader Lift Height LA1065: 111.2 in 112 in Loader Lift Capacity (Full Height) LA1065: 2275 lb 2,500 lb Loader Breakout Force Not Published 3,114 lbf ▶ WarrantyWarranty Length & Coverage Not Published 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain
