▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-TE4 V2403-CR-TE4-GL1 Engine Type 4-cylinder, turbocharged, common-rail, liquid-cooled diesel Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 148.6 in³ 148.5 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 54.7 hp 52 hp PTO Power F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry, dual element Dry paper, dual element Fuel System Common rail direct injection Electronic Common Rail System (CRS) Alternator 45 A 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 9.5 gpm 9.8 gpm Steering Flow 4.9 gpm 4.9 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 14.7 gpm Overall Hydraulic Pump Flow Not Published 14.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (optional) Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 6.9 qt 8.7 qt Crankcase Capacity 9.9 qt 9.9 qt Transmission / Hydraulic System Capacity 11.6 gal 11.9 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent hydraulic PTO with PTO brake, wet clutch Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2550 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category I and II SAE Category I & II Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 2,310 lb 2,976 lb Lift Control Type Position control standard, draft control optional Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th); HST (4WD): hydrostatic transmission, 3-range Glide Shift No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 12Fx8R Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph 16.5 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph 15.8 mph Clutch F (2WD gear), DT (4WD gear): dry single plate; HST (4WD): no clutch Dry type single stage Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Wet disc type, mechanically activated Seat Suspension & Adjustability High-back suspension seat Suspension seat with swivel function Front Axle Type 4WD: Bevel gear type 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 1,650 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 67.3 in Wheelbase 74.6 in 75.4 in Ground Clearance 15.2 in 15.4 in Min. Turn Radius without Brakes F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (with brake applied) 9.2 ft (with brake applied) Height to Top of ROPS 95.7 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (without 3-point hitch) 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD gear): 3,474 lb; DT (4WD gear): 3,716 lb; HST (4WD): 3,734 lb 3,979 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-26 14.9-26; 13.6-28 R3 Turf - Front Not Published 29X12.50-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1065: 2-lever quick coupler standard 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model LA1065 LA1055 Loader Lift Height LA1065: 111.2 in (at pivot pin) 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) LA1065: 2,275 lb (at pivot pin) 2,361 lb (at pivot pin) Loader Breakout Force Not Published 3,171 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
