▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-TE4 F2803-ELA Engine Type 4-cylinder, turbocharged, common-rail, liquid-cooled diesel Vertical, water-cooled, 4-cycle diesel, 5-cylinder No. of Cylinders 4 5 Displacement 148.6 in³ 167.6 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 54.7 hp 54 hp PTO Power F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp 45 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry, dual element Dual dry elements Fuel System Common rail direct injection Not Published Alternator 45 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.5 gpm Not Published Steering Flow 4.9 gpm Not Published Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 17.1 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal ROPS: 17.2 gal; Cab: 25.1 gal Coolant Capacity 6.9 qt 7.7 qt Crankcase Capacity 9.9 qt 8.5 qt Transmission / Hydraulic System Capacity 11.6 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent hydraulic PTO with PTO brake, wet clutch Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II/I Hitch Lift Capacity Not Published 4,200 lb Hitch Lift Capacity (at 24”) 2,310 lb 3,307 lb Lift Control Type Position control standard, draft control optional Position, draft and mix control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th); HST (4WD): hydrostatic transmission, 3-range Synchronized shuttle, 8F/8R (12F/12R with creeper) No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 8F/8R (12F/12R with creeper) Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph Not Published Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph Not Published Clutch F (2WD gear), DT (4WD gear): dry single plate; HST (4WD): no clutch Not Published Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Mechanical wet disc Seat Suspension & Adjustability High-back suspension seat Not Published Front Axle Type 4WD: Bevel gear type Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,650 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 67.2 in (minimum) Wheelbase 74.6 in ROPS: 78.7 in; Cab: 81.7 in Ground Clearance 15.2 in 16.9 in Min. Turn Radius without Brakes F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (with brake applied) Not Published Height to Top of ROPS 95.7 in 93.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 98.1 in Overall Length F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (without 3-point hitch) 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in ▶ WeightTractor Weight (Base) F (2WD gear): 3,474 lb; DT (4WD gear): 3,716 lb; HST (4WD): 3,734 lb 2WD ROPS: 3,748 lb; 4WD ROPS: 3,968 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear Standard: 6.5-16 front (2WD), 9.5-22 front (4WD), 14.9-28 rear R1 Agricultural - Front F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 8.3-24 R1 Agricultural - Rear 14.9-26 14.9-28 R3 Turf - Front Not Published 2WD: 9.00-10; 4WD: 29x12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R3 R4 Industrial - Front Not Published 12.5/80-18 R4 R4 Industrial - Rear Not Published 16.9-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System LA1065: 2-lever quick coupler standard Not Published Loader Model LA1065 LA1002 Loader Lift Height LA1065: 111.2 in (at pivot pin) LA1002: 115.6 in Loader Lift Capacity (Full Height) LA1065: 2,275 lb (at pivot pin) LA1002: 2,579 lb (at pivot pin) Loader Breakout Force Not Published LA1002: 3,330 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
