▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403CR-T V3307-DI Engine Type Common rail direct injection, liquid-cooled, turbocharged 4-cylinder diesel 4-cylinder inline, direct injected diesel No. of Cylinders 4 4 Displacement 148.6 in³ 203 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 54.7 hp Not Published PTO Power F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry, dual element 8 in dry, dual element Fuel System Common rail direct injection Direct injection Alternator 45 A ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.5 gpm 11.0 gpm Steering Flow 4.9 gpm 6.1 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow Not Published 17 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 (optional) 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 13.5 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 6.9 qt 8.5 qt Crankcase Capacity 9.9 qt 11.6 qt Transmission / Hydraulic System Capacity 11.6 gal 10.6 gal Front Axle Fluid Capacity Not Published 8.5 qt ▶ PTO & HitchPTO Type Live independent hydraulic PTO with PTO brake, wet clutch Live independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II Hitch Lift Capacity Not Published 4189 lb Hitch Lift Capacity (at 24”) 2310 lb 3307 lb Lift Control Type Position control standard, draft control optional Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th, 2-range); HST (4WD): Hydrostatic transmission, 3-range Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph 18 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph 18.0 mph Clutch F (2WD gear), DT (4WD gear): Dry single plate; HST (4WD): No clutch Dry single plate (synchro shuttle) / multiple wet disks (hydraulic shuttle) Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Multiple wet disc, mechanical Seat Suspension & Adjustability High-back suspension seat Reclining, fully adjustable seat (height, weight, fore and aft, arm rests) with retractable seat belt; optional air ride seat suspension (cab) Front Axle Type 4WD: Bevel gear type 4WD: Bevel gear type with Easy-To-Shift 4WD engagement while rolling Front Axle Rating Not Published Not Published Drawbar Capacity 1650 lb 2200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (w/o 3P) (without 3-point hitch) 2WD: 140.4 in; 4WD: 135.6 in Overall Width 69.7 in 73.2 in Wheelbase 74.6 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance F (2WD gear): 15.9 in; DT (4WD gear), HST (4WD): 15.2 in 15.4 in Min. Turn Radius without Brakes F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (w/brake) (with brake applied) 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 95.7 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.8 in ▶ WeightTractor Weight (Base) F (2WD gear): 3474 lb; DT (4WD gear): 3716 lb; HST (4WD): 3734 lb 2WD ROPS: 4650 lb; 4WD ROPS: 4785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 2WD: 7.50-16; 4WD: 9.5-24 R1 Agricultural - Rear 14.9-26 16.9-28 R3 Turf - Front Not Published 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear Not Published 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 (4WD) R4 Industrial - Rear Not Published 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System LA1065: 2-lever quick coupler standard LA1153: two-lever quick coupler Loader Model LA1065 LA1153 Loader Lift Height LA1065: 111.2 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) LA1065: 2275 lb Not Published Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
