▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403CR-T V2403-CR-TE4 Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged 4-cylinder, turbocharged, common-rail diesel No. of Cylinders 4 4 Displacement 148.6 in³ 148.5 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 57 hp 58.7 hp PTO Power 46.5 hp 50 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled, pressurized radiator with recovery tank Air Cleaner Dry-dual element Dry paper dual element, 8 in diameter, pre-cleaner standard Fuel System Common Rail System (CRS), direct injection Common rail direct injection Alternator 45 A, 12 V 45 A ▶ HydraulicsPump Type Gear Gear pump Implement Flow 9.5 gpm 10.6 gpm Steering Flow 4.9 gpm 6.1 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 16.5 gpm Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 16.5 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 (SCD) No. of Optional Remote Valves Maximum 3 (opt) 2 optional (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 17.2 gal Coolant Capacity 6.9 qt 8.5 qt Crankcase Capacity 7.4 qt 7.6 qt Transmission / Hydraulic System Capacity 11.6 gal 50.7 qt Front Axle Fluid Capacity 8.9 qt No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Hydraulic, independent PTO, self-modulating multi-plate wet clutch with brake PTO Rear 540 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II Category I and II Hitch Lift Capacity 2,870 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,310 lb 3,307 lb Lift Control Type Position (std), Draft (opt) Position control ▶ Transmission & DrivetrainTransmission Type 3-range hydrostatic (HST) Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R No. of Speeds 3-range 8F/8R Max Travel Speed (Forward) DT (2WD/4WD): 17.3 mph; HST (4WD): 17.7 mph 18.2 mph Max Travel Speed (Reverse) DT (2WD/4WD): 15.9 mph; HST (4WD): 16.0 mph 18.6 mph Clutch No clutch Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Mechanical wet disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Fully adjustable suspension seat with retractable seat belt Front Axle Type Bevel gear type (4WD) M5660SUH: adjustable tubular-steel 2WD axle; M5660SUHD: cast-iron bevel-pinion drive, 55-degree turning angle, 4WD Front Axle Rating Not Published 4,410 lb at 55.9 in tread spacing (M5660SUH); 5,290 lb at 55.9 in tread spacing (M5660SUHD) Drawbar Capacity 1,650 lb 3,300 lb (maximum tongue weight) ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 72.8 in Wheelbase 74.6 in 82 in (M5660SUH); 80.7 in (M5660SUHD) Ground Clearance 15.2 in 16.3 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 11.1 ft (M5660SUH); 12.8 ft (M5660SUHD) Height to Top of ROPS 95.7 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 125.9 in (without 3-point hitch) 138.7 in (M5660SUH); 136 in (M5660SUHD) ▶ WeightTractor Weight (Base) 3,734 lb (with ROPS) 4,189 lb (M5660SUH); 4,387 lb (M5660SUHD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 R1 Agricultural - Front 9.5-16 9.5L-15 (M5660SUH); 9.5-22 (M5660SUHD) R1 Agricultural - Rear 14.9-26 14.9-28 R3 Turf - Front Not Published 29x12.50-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 12.5/80-18 (M5660SUHD) R4 Industrial - Rear Not Published 16.9-24 (M5660SUHD) ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment LA1154SU: 2-lever quick attach coupler standard Loader Model LA1065 LA1154SU Loader Lift Height 111.2 in (at pivot pin) LA1154SU: 130.9 in (height position); 115.7 in (power position) Loader Lift Capacity (Full Height) 2,275 lb (at pivot pin) LA1154SU: 2,469 lb (height position); 2,928 lb (power position) Loader Breakout Force 3,102 lbf LA1154SU: 4,230 lbf (height position); 5,354 lbf (power position) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage ▶ ITC Company AccessoriesAccessories that fit None tagged yet
