▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403CR-T V3307-DI Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged 4-cylinder inline, direct injected diesel No. of Cylinders 4 4 Displacement 148.6 in³ 203 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 57 hp Not Published PTO Power 46.5 hp 55 hp Engine Emissions Constraints Not Published Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry-dual element 8 in dry, dual element Fuel System Common Rail System (CRS), direct injection Direct injection Alternator 45 A, 12 V ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.5 gpm 11.0 gpm Steering Flow 4.9 gpm 6.1 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Maximum 3 (opt) 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 13.5 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 6.9 qt 8.5 qt Crankcase Capacity 7.4 qt 11.6 qt Transmission / Hydraulic System Capacity 11.6 gal 59.2 qt Front Axle Fluid Capacity 8.9 qt Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II Category I and II Hitch Lift Capacity 2,870 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,310 lb 3,307 lb Lift Control Type Position (std), Draft (opt) Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 3-range hydrostatic (HST) Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 3-range 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) DT (2WD/4WD): 17.3 mph; HST (4WD): 17.7 mph 17.8 mph Max Travel Speed (Reverse) DT (2WD/4WD): 15.9 mph; HST (4WD): 16.0 mph 18.0 mph Clutch No clutch Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Multiple wet disc, mechanical Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Bevel gear type (4WD) 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity 1,650 lb 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 73.2 in Wheelbase 74.6 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 15.2 in 15.4 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 95.7 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable 99.8 in Overall Length 125.9 in (without 3-point hitch) 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 3,734 lb (with ROPS) 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5-16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 14.9-26 16.9-28 R3 Turf - Front Not Published 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear Not Published 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 (4WD) R4 Industrial - Rear Not Published 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment LA1153: two-lever quick coupler Loader Model LA1065 LA1153 Loader Lift Height 111.2 in (at pivot pin) LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) 2,275 lb (at pivot pin) Not Published Loader Breakout Force 3,102 lbf Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
