▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V2403CR-T L3C19-T Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 4 3 Displacement 148.6 in³ 114.7 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 57 hp 57 hp PTO Power 46.5 hp 48.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry-dual element Dry Fuel System Common Rail System (CRS), direct injection Common rail direct injection (CRDI) Alternator 45 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.5 gpm 8.2 gpm Steering Flow 4.9 gpm 4.1 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 12.3 gpm Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 12.3 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 3 Pair (2 Detent, 1 STD) No. of Optional Remote Valves Maximum 3 (opt) Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 10.6 gal Coolant Capacity 6.9 qt Not Published Crankcase Capacity 7.4 qt 6.2 qt Transmission / Hydraulic System Capacity 11.6 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch I & II Category II Hitch Lift Capacity 2870 lb 2,755 lb Hitch Lift Capacity (at 24”) 2310 lb 2,469 lb Lift Control Type Position (std), Draft (opt) Position & Draft ▶ Transmission & DrivetrainTransmission Type 8-speed gear-drive (synchronized shuttle) Synchro shuttle No. of Speeds 8F/8R F16 x R16 Max Travel Speed (Forward) 17.3 mph Not Published Max Travel Speed (Reverse) 15.9 mph Not Published Clutch Dry single plate Not Published Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Mechanical wet disc Wet, Multi-disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Not Published Front Axle Type Not Published Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 1650 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 127.8 in (without 3-point hitch) 133 in Overall Width 69.7 in 62.5 in Wheelbase 74.6 in 73.2 in Ground Clearance 15.2 in Not Published Min. Turn Radius without Brakes 8.5 ft (with brake applied) Not Published Height to Top of ROPS 95.7 in 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,474 lb 3,869 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 7.5L-15 / 14.9-26 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7.5L-15 9.5-16 R1 Agricultural - Rear 14.9-26 13.6-24 R3 Turf - Front Not Published 28x8.5-15 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) Loader Model LA1065 LL4106; LL4001 Loader Lift Height 111.2 in LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) 2275 lb LL4106: 2,680 lb; LL4001: 2,998 lb Loader Breakout Force 3102 lbf (19.7 in forward of pivot pin) LL4106: 4,063 lb; LL4001: 4,295 lb ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 72 months or 3000 hours. Commercial Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. 6-year limited powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
