▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403CR-T V2403CR-T Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 148.6 in³ 148.6 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 63.4 hp 57 hp PTO Power 51.8 hp 46.5 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry-dual element Dry-dual element Fuel System Common Rail System (CRS), direct injection Common Rail System (CRS), direct injection Alternator 45 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 9.5 gpm 9.5 gpm Steering Flow 4.9 gpm 4.9 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 14.4 gpm (9.5 + 4.9, computed) Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Maximum 3 (opt) Maximum 3 (opt) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 6.9 qt 6.9 qt Crankcase Capacity 7.4 qt 7.4 qt Transmission / Hydraulic System Capacity 11.6 gal 11.6 gal Front Axle Fluid Capacity 8.9 qt 8.9 qt ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Live independent, hydraulic PTO with PTO brake, wet clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II I & II Hitch Lift Capacity 2,870 lb 2,870 lb Hitch Lift Capacity (at 24”) 2,310 lb 2,310 lb Lift Control Type Position (std), Draft (opt) Position (std), Draft (opt) ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission 3-range hydrostatic (HST) No. of Speeds 3-range 3-range Max Travel Speed (Forward) 17.7 mph DT (2WD/4WD): 17.3 mph; HST (4WD): 17.7 mph Max Travel Speed (Reverse) 16.0 mph DT (2WD/4WD): 15.9 mph; HST (4WD): 16.0 mph Clutch No clutch No clutch Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Mechanical wet disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) High-back suspension seat (optional arm rests) Front Axle Type Bevel gear type (4WD) Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,650 lb 1,650 lb ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 69.7 in Wheelbase 74.6 in 74.6 in Ground Clearance 15.2 in 15.2 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 8.9 ft (with brake applied) Height to Top of ROPS 95.7 in 95.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Applicable Overall Length 125.9 in (without 3-point hitch) 125.9 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,734 lb (with ROPS) 3,734 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 Standard ag: 9.5-16 / 14.9-26 R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-26 14.9-26 R3 Turf - Front 29 x 12.5-15 Not Published R3 Turf - Rear 44x18-20 Not Published R4 Industrial - Front 12-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment 1065A: 2-Lever Quick Coupler for Loader Attachment Loader Model LA1065 LA1065 Loader Lift Height 111.2 in (at pivot pin) 111.2 in (at pivot pin) Loader Lift Capacity (Full Height) 2,275 lb (at pivot pin) 2,275 lb (at pivot pin) Loader Breakout Force 3,102 lbf 3,102 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit
