▶ EngineEngine Manufacturer Kubota FPT Engine Model V2403CR-T S8000 Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged 3-cylinder, Tier 4 B/Final, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 148.6 in³ 178.8 in³ Rated Engine Speed 2700 rpm 2300 rpm Engine Power (Gross) 63.4 hp 64 hp PTO Power 51.8 hp 50 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry-dual element Not Published Fuel System Common Rail System (CRS), direct injection Electronic high pressure common rail Alternator 60 A 120 A ▶ HydraulicsPump Type Gear Fixed displacement Implement Flow 9.5 gpm 12.6 gpm Steering Flow 4.9 gpm Not Published Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 12.6 gpm Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) Not Published Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Maximum 3 (opt) 3 ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 21.7 gal Coolant Capacity 6.9 qt Not Published Crankcase Capacity 7.4 qt Not Published Transmission / Hydraulic System Capacity 11.6 gal Not Published Front Axle Fluid Capacity 8.9 qt Not Published ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Independent PTO Rear 540 rpm 540 (standard); 540/540E (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II Category I/II Hitch Lift Capacity 2,870 lb 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 2,310 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Position (std), Draft (opt) Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 mechanical shuttle (dry clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds 3-range MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) 17.7 mph 18.6 mph Max Travel Speed (Reverse) 16.0 mph Not Published Clutch No clutch MFD: wet clutch (12x12 power shuttle); 2WD: dry clutch (8x8 mechanical shuttle) Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Mechanical wet disc Wet disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Mechanical contoured seat, adjustable; optional air-suspension seat Front Axle Type Bevel gear type (4WD) 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity 1,650 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 69.7 in Not Published Wheelbase 74.6 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance 15.2 in Not Published Min. Turn Radius without Brakes 8.9 ft (with brake applied) Not Published Height to Top of ROPS Not Published Not Applicable Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.7 in 2WD: 98 in; MFD: 100 in Overall Length 125.9 in (without 3-point hitch) 155.3 in ▶ WeightTractor Weight (Base) 4,268 lb (with cab) 2WD Cab: 6,173 lb; MFD Cab: 6,834 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front 9.5-16 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear 14.9-26 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front 29 x 12.5-15 Not Published R3 Turf - Rear 44x18-20 Not Published R4 Industrial - Front 12-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment Not Published Loader Model LA1065 L610 Loader Lift Height 111.2 in (at pivot pin) 120 in Loader Lift Capacity (Full Height) 2,275 lb (at pivot pin) NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force 3,102 lbf Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
