▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403CR-T V3307-CR-TE4 Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged Liquid-cooled, diesel, 4-cylinder No. of Cylinders 4 4 Displacement 148.6 in³ 203 in³ Rated Engine Speed 2700 rpm 2400 rpm Engine Power (Gross) 63.4 hp 65.4 hp PTO Power 51.8 hp 52 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry-dual element Dual element (primary and secondary elements) Fuel System Common Rail System (CRS), direct injection Common Rail System (CRS) Alternator 60 A 130 A ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.5 gpm 16.7 gpm Steering Flow 4.9 gpm 6.3 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 23.0 gpm (16.7 + 6.3, computed) Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 (SCD / FD) No. of Optional Remote Valves Maximum 3 (opt) Max. 3 ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 23.8 gal Coolant Capacity 6.9 qt 10.6 qt Crankcase Capacity 7.4 qt 12.7 qt Transmission / Hydraulic System Capacity 11.6 gal 49.6 qt Front Axle Fluid Capacity 8.9 qt 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II I / II Hitch Lift Capacity 2,870 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,310 lb 3,307 lb Lift Control Type Position (std), Draft (opt) Position, draft (top link sensing) & mixed control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) No. of Speeds 3-range F12/R12 (option: F18/R18 with creep) Max Travel Speed (Forward) 17.7 mph 24.9 mph Max Travel Speed (Reverse) 16.0 mph 24.7 mph Clutch No clutch Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Ultra Grand Cab II Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Hydraulic wet disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Front Axle Type Bevel gear type (4WD) Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,650 lb 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 75.6 in Wheelbase 74.6 in 84.1 in Ground Clearance 15.2 in 18.1 in (front axle crop clearance) Min. Turn Radius without Brakes 8.9 ft (with brake applied) 11.8 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.7 in 101 in Overall Length 125.9 in (without 3-point hitch) 144 in ▶ WeightTractor Weight (Base) 4,268 lb (with cab) 6,008 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 9.5-16 320/70R24 R1 Agricultural - Rear 14.9-26 420/75R34 R3 Turf - Front 29 x 12.5-15 9.50-24 R3 Turf - Rear 44x18-20 18.4-26 R4 Industrial - Front 12-16.5 14-17.5 R4 Industrial - Rear 17.5L-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment LA1154A: 2-Lever Quick Coupler Loader Model LA1065 LA1154A Loader Lift Height 111.2 in (at pivot pin) LA1154A: Height position: 133.0 in; Power position: 117.6 in Loader Lift Capacity (Full Height) 2,275 lb (at pivot pin) LA1154A: Height position: 2,674 lb; Power position: 2,928 lb Loader Breakout Force 3,102 lbf LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
