▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403CR-T V3307-CR-TE4 Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 148.6 in³ 203 in³ Rated Engine Speed 2700 rpm 2400 rpm Engine Power (Gross) 63.4 hp 66.4 hp PTO Power 51.8 hp 56 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry-dual element Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common Rail System (CRS), direct injection Common Rail System (CRS) Alternator 60 A 45 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 9.5 gpm 11.0 gpm Steering Flow 4.9 gpm 6.1 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 17.1 gpm Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 17.1 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves Not Published 1 (SCD) No. of Optional Remote Valves Maximum 3 (opt) 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 18.5 gal Coolant Capacity 6.9 qt 8.5 qt Crankcase Capacity 7.4 qt 12.7 qt Transmission / Hydraulic System Capacity 11.6 gal 14.8 gal Front Axle Fluid Capacity 8.9 qt 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II I / II Hitch Lift Capacity 2,870 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,310 lb 3,307 lb Lift Control Type Position (std), Draft (opt) Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Hydraulic-shuttle transmission (fully synchronized) No. of Speeds 3-range F8/R8 Max Travel Speed (Forward) 17.7 mph 18.0 mph Max Travel Speed (Reverse) 16.0 mph 17.7 mph Clutch No clutch Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Mechanical wet disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Suspension seat, adjustable (travel, suspension tension, backrest tilt, armrests); optional air-suspension seat on cab models Front Axle Type Bevel gear type (4WD) Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,290 lb (6,615 lb with loader) Drawbar Capacity 1,650 lb 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 73.0 in Wheelbase 74.6 in 83.1 in Ground Clearance 15.2 in 18.1 in (crop clearance at front axle); 15.4 in (minimum ground clearance) Min. Turn Radius without Brakes 8.9 ft (with brake applied) 11.8 ft Height to Top of ROPS Not Published 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.7 in n/a (ROPS model) Overall Length 125.9 in (without 3-point hitch) 138 in ▶ WeightTractor Weight (Base) 4,268 lb (with cab) 5,005 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 Standard: 9.5-24 front, 16.9-28 rear R1 Agricultural - Front 9.5-16 9.5-24 R1 Agricultural - Rear 14.9-26 16.9-28/14.9-28 R3 Turf - Front 29 x 12.5-15 LSW305-521 R3 Turf - Rear 44x18-20 LSW570-648 R4 Industrial - Front 12-16.5 12.5/80-18 R4 Industrial - Rear 17.5L-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment LA1154A: 2-Lever Quick Coupler Loader Model LA1065 LA1154A Loader Lift Height 111.2 in (at pivot pin) Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) 2,275 lb (at pivot pin) Height position: 2,469 lb; Power position: 2,928 lb Loader Breakout Force 3,102 lbf Height position: 4,230 lbf; Power position: 5,354 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit
