▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V2403CR-T L4C25-T Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged In-line vertical, water cooled 4-cycle diesel, CRDI No. of Cylinders 4 4 Displacement 148.6 in³ 152.85 in³ Rated Engine Speed 2700 rpm 2500 rpm Engine Power (Gross) 63.4 hp 63 hp PTO Power 51.8 hp 54.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry-dual element Dry Fuel System Common Rail System (CRS), direct injection Delphi, CRDI Alternator 60 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear Gear type, engine drive Implement Flow 9.5 gpm 14.5 gpm Steering Flow 4.9 gpm 6.6 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 21.1 gpm Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 21.1 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 Pairs (Front), 2 Pairs (Rear) No. of Optional Remote Valves Maximum 3 (opt) Not Published ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 24.3 gal Coolant Capacity 6.9 qt 3.0 gal Crankcase Capacity 7.4 qt 1.8 gal Transmission / Hydraulic System Capacity 11.6 gal 16.5 gal Front Axle Fluid Capacity 8.9 qt 2.3 gal ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Independent PTO Rear 540 rpm 540 / 540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II Category II Hitch Lift Capacity 2870 lb 4,079 lb Hitch Lift Capacity (at 24”) 2310 lb 3,483 lb Lift Control Type Position (std), Draft (opt) Position & Draft ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Synchro Shuttle No. of Speeds 3-range F16 x R16 Max Travel Speed (Forward) 17.7 mph Not Published Max Travel Speed (Reverse) 16.0 mph Not Published Clutch No clutch Dry single clutch Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Mechanical wet disc Wet, Multi-disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Seat With Suspension & Armrest Front Axle Type Bevel gear type (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1650 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 125.9 in (without 3-point hitch) 140 in Overall Width 69.7 in 72.6 in Wheelbase 74.6 in 83.1 in Ground Clearance 15.2 in Not Published Min. Turn Radius without Brakes 8.9 ft (with brake applied) 12.8 ft (3.9 m) Height to Top of ROPS Not Published 113.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.7 in Not Published ▶ WeightTractor Weight (Base) 4268 lb 5,313 lb Weight with ROPS and Loader Not Published 6,503 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D R1 Agricultural - Front 9.5-16 9.5-24 (Standard Ag); 11.2-24 (Large Ag) R1 Agricultural - Rear 14.9-26 16.9-28 (Standard Ag); 16.9-30 (Large Ag) R3 Turf - Front 29x12.50-15 Not Published R3 Turf - Rear 44x18-20 Not Published R4 Industrial - Front 12-16.5 10.5/80x18 10PR R4 Industrial - Rear 17.5L-24 19.5Lx24 8PR ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) Loader Model LA1065 LL5001 Loader Lift Height 111.2 in LL5001: 132.9 in (height position); 116.8 in (power position) Loader Lift Capacity (Full Height) 2275 lb LL5001: 3,426 lb (height position); 3,488 lb (power position) Loader Breakout Force 3102 lbf (19.7 in forward of pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 72 months or 3000 hours. Commercial Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
