▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V2403CR-T L4C25-T Engine Type Liquid-cooled, diesel, 4-cylinder, Turbocharged In-line vertical, water cooled 4-cycle diesel, CRDI No. of Cylinders 4 4 Displacement 148.6 in³ 152.85 in³ Rated Engine Speed 2700 rpm 2500 rpm Engine Power (Gross) 63.4 hp 63 hp PTO Power 51.8 hp 54.1 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry-dual element Not Published Fuel System Common Rail System (CRS), direct injection Not Published Alternator 60 A 70 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.5 gpm 14.5 gpm Steering Flow 4.9 gpm 6.6 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) 21.1 gpm Overall Hydraulic Pump Flow 14.4 gpm (9.5 + 4.9, computed) 21.1 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 Pairs (Front), 2 Pairs (Rear) No. of Optional Remote Valves Maximum 3 (opt) Not Published ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 24.3 gal Coolant Capacity 6.9 qt Not Published Crankcase Capacity 7.4 qt Not Published Transmission / Hydraulic System Capacity 11.6 gal Not Published Front Axle Fluid Capacity 8.9 qt Not Published ▶ PTO & HitchPTO Type Live independent, hydraulic PTO with PTO brake, wet clutch Independent PTO Rear 540 rpm 540 / 540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I & II Category II Hitch Lift Capacity 2,870 lb Not Published Hitch Lift Capacity (at 24”) 2,310 lb 3,483 lb Lift Control Type Position (std), Draft (opt) Position & Draft ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Synchro Shuttle No. of Speeds 3-range F16 x R16 Max Travel Speed (Forward) 17.7 mph Not Published Max Travel Speed (Reverse) 16.0 mph Not Published Clutch No clutch Not Published Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Mechanical wet disc Wet, Multi-disc Seat Suspension & Adjustability High-back suspension seat (optional arm rests) Not Published Front Axle Type Bevel gear type (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,650 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 69.7 in 72.6 in Wheelbase 74.6 in 83.1 in Ground Clearance 15.2 in Not Published Min. Turn Radius without Brakes 8.9 ft (with brake applied) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.7 in 105.4 in Overall Length 125.9 in (without 3-point hitch) 140 in (bumper to link) ▶ WeightTractor Weight (Base) 4,268 lb (with cab) 5,776 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 6,966 lb (5,776 + 1,190, computed) ▶ Tire OptionsTire Size & Options Standard ag: 9.5-16 / 14.9-26 Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D R1 Agricultural - Front 9.5-16 9.5-24 (Standard Ag); 11.2-24 (Large Ag) R1 Agricultural - Rear 14.9-26 16.9-28 (Standard Ag); 16.9-30 (Large Ag) R3 Turf - Front 29 x 12.5-15 Not Published R3 Turf - Rear 44x18-20 Not Published R4 Industrial - Front 12-16.5 10.5/80x18 10PR R4 Industrial - Rear 17.5L-24 19.5Lx24 8PR ▶ Loader & AttachmentsQuick Attach Loader System 1065A: 2-Lever Quick Coupler for Loader Attachment Not Published Loader Model LA1065 LL5001 Loader Lift Height 111.2 in (at pivot pin) LL5001: 132.9 in (height position); 116.8 in (power position) Loader Lift Capacity (Full Height) 2,275 lb (at pivot pin) LL5001: 3,426 lb (height position, at pivot pin, max height); 3,488 lb (power position, at pivot pin, max height) Loader Breakout Force 3,102 lbf Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
