▶ EngineEngine Manufacturer Yanmar YANMAR Engine Model 3TNV76F 3TNM74F Engine Type 3-cylinder, indirect injection (swirl chamber), water-cooled 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 68.0 in³ 60.6 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 21.5 hp 21.5 hp PTO Power 15 hp 15.6 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid cooled Air Cleaner Dry Not Published Fuel System In-line injection pump Not Published Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Gear pump, transmission driven Not Published Implement Flow 4.6 gpm 4.3 gpm Steering Flow 2.1 gpm 3.7 gpm Total Hydraulic Flow 6.7 gpm 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 6.7 gpm 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 1 set (2 quick couplers, optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.1 gal Coolant Capacity 0.9 gal 3.0 qt Crankcase Capacity 0.8 gal 3.1 qt Transmission / Hydraulic System Capacity 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) 4.1 gal Front Axle Fluid Capacity 0.5 gal 3.17 qt ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent, hydraulic clutch PTO Rear Standard (540 rpm) 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines Mid-PTO Availability Standard (2,500 rpm) Independent mid-PTO, 2,057 rpm at 3,200 engine rpm, SAE 16/32, 15 splines Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 992 lb Not Published Hitch Lift Capacity (at 24”) 728 lb 660 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Drive Hydrostatic transmission, dual range speeds No. of Speeds 2 ranges Infinite forward and reverse (hydrostatic); 2 ranges Max Travel Speed (Forward) 8.70 mph 9.5 mph (high range, with R4 tires) Max Travel Speed (Reverse) 5.22 mph 6.6 mph (high range, with R4 tires) Clutch N/A Not Published Differential Lock & Limited Slip Options Mechanical pedal type Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Full-frame chassis Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability High-back seat, folding armrest, retractable seat belt, fore-aft adjustment Fore-and-aft adjustable operator seat Front Axle Type Front wheel mechanical assist (4WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal Not Published ▶ Dimensions & ManeuverabilityOverall Width 47 in 47.3 in (with R4 tires) Wheelbase 56 in 57.9 in Ground Clearance Not Published 6.4 in (with R4 tires) Min. Turn Radius without Brakes 7.87 ft 7.87 ft Height to Top of ROPS 87 in 82.3 in (with R4 tires) Height to Top of ROPS (folded) Not Published 66.3 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published Overall Length 97 in (bumper to link) 102.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,433 lb 1,537 lb (with ROPS, R4 tires) Weight with ROPS and Loader Not Published 1,962 lb (1,537 + 425, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R3 Turf; R4 Industrial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.50-10 18x8.50-10 4PR R3 Turf - Rear 26x12.0-12 26x12.0-12 4PR R4 Industrial - Front 18x8.50-10 18x8.50-10 6PR R4 Industrial - Rear 26x12.0-12 26x12.0-12 4PR ▶ Loader & AttachmentsQuick Attach Loader System LL1102: quick attachment (ISO 24410 attachments only), latch handle with latch pin YL110: YANMAR quick attachment system Loader Model LL1102; LL1700; LL1001 YL110 Loader Lift Height LL1001: 72.6 in (at pivot pin) YL110: 71 in to pivot pin (51 in under level bucket) Loader Lift Capacity (Full Height) LL1001: 902 lb (at pivot pin, maximum height) YL110: 825 lb at pivot pin Loader Breakout Force LL1001: 1,836 lb (at pivot pin) YL110: 1,342 lb at pivot pin ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year
