▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV80F-ZXKLST 3TNV80F-NXDKTFX Engine Type 3-cylinder, indirect injection (swirl chamber) 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 77.3 in³ 77.3 in³ Rated Engine Speed 2800 rpm 3000 rpm Engine Power (Gross) 24.7 hp 24.7 hp PTO Power 19.3 hp 18.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry Single dry Fuel System In-line injection pump IDI Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Engine driven Single gear pump Implement Flow 5.6 gpm 4.17 gpm Steering Flow 3.7 gpm 2.77 gpm Total Hydraulic Flow 9.3 gpm 6.94 gpm Overall Hydraulic Pump Flow 9.3 gpm 6.94 gpm Hydraulic System Type Open center system, position control Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 1 pair (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.79 gal 8.4 gal Coolant Capacity 0.9 gal 0.95 gal Crankcase Capacity 0.8 gal Not Published Transmission / Hydraulic System Capacity 4.5 gal 4.49 gal Front Axle Fluid Capacity 0.8 gal 1.18 gal ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Optional (2,500 rpm) Available (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,896 lb 1,550 lb Hitch Lift Capacity (at 24”) 1,323 lb 560 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Drive HST No. of Speeds 3 ranges 2 Max Travel Speed (Forward) 12.86 mph 13.57 mph Max Travel Speed (Reverse) 8.45 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydraulic Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Mechanical suspension seat Front Axle Type Four wheel drive (4WD) Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 48.7 in 56.29 in Wheelbase 63.4 in 61.02 in Ground Clearance Not Published 10.23 in Min. Turn Radius without Brakes 8.2 ft (with brake) 110.23 in Height to Top of ROPS 86.4 in 85.94 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 111.9 in (frame to link) 105.11 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,764 lb 2,207 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options IND (R4 Industrial), Versa Turf R3 Turf, R4 Industrial, Hybrid R1 Agricultural - Front 7-12 Not Published R1 Agricultural - Rear 11.2-16 Not Published R3 Turf - Front 22x8.50-12 23x8.5-12 R3 Turf - Rear 31x15.50-15 33x12.5-16.5 R4 Industrial - Front 23x8.50-12 23x8.5-14 R4 Industrial - Rear 12-16.5 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System LL2300: Bobcat type quick attach L2025P: Quick attach mechanism Loader Model LL2300; LL2001 L2025P Loader Lift Height LL2300: 84.4 in; LL2001: 84.4 in L2025P: 87.7 in Loader Lift Capacity (Full Height) LL2300: 1,067 lb; LL2001: 1,127 lb (at pivot pin) L2025P: 1,380 lb (at pivot pin) Loader Breakout Force LL2300: 2,290 lb; LL2001: 1,744 lb (at pivot pin) L2025P: 2,059 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
