▶ EngineEngine Manufacturer MHI Yanmar Engine Model S3L2-W463GTAC 3TNV80F Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI Water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.6 hp PTO Power 19.2 hp 18.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled, forced circulation Air Cleaner Dry Single element, dry Fuel System IDI (indirect injection) Indirect injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Gear pump Implement Flow 7.9 gpm 4.2 gpm Steering Flow 4.6 gpm 2.8 gpm Total Hydraulic Flow 12.5 gpm 7.0 gpm Overall Hydraulic Pump Flow 12.5 gpm 6.95 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 (1 pair optional) Not Published No. of Optional Remote Valves 1 pair (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 5.8 gal Coolant Capacity Not Published 0.95 gal Crankcase Capacity Not Published 0.71 gal Transmission / Hydraulic System Capacity Not Published 3.83 gal Front Axle Fluid Capacity Not Published 0.85 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Standard, 2,000 rpm Category, 3-Point Hitch Category I Category I (N) Hitch Lift Capacity 1,808 lb 1,323 lb Hitch Lift Capacity (at 24”) 1433 lb 1,101 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic (HST) with mechanical H/L constant-mesh range No. of Speeds F12 x R12 2 range (H/L) Max Travel Speed (Forward) Not Published 10.5 mph (H range, Ag tires) Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single None (HST) Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Rear differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsFrame Type Not Published Sub-compact tractor; selectable 4WD Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet disc, foot operated Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119 in 104 in Overall Width 66 in 45.8 in Wheelbase 66 in 57.5 in Ground Clearance Not Published 9.4 in Min. Turn Radius without Brakes 11.5 ft (3.5 m) Not Published Height to Top of ROPS 95 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,985 lb 1,610 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R4 industrial, R3 turf and VT (versa turf); VT same size as R4 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 6-12 R1 Agricultural - Rear 11.2-24 9.5-16 R3 Turf - Front 25x8.50-14 20x8-10 R3 Turf - Rear 41x14.00-20 29x12.5-15 R4 Industrial - Front 27x8.50-15 23x8.5-12 R4 Industrial - Rear 43x16.00-20 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler Quick attach front loader Loader Model LL3002 BBL105 Loader Lift Height LL3002: 94.3 in 75.5 in Loader Lift Capacity (Full Height) LL3002: 1,599 lb 992 lb Loader Breakout Force LL3002: 2,962 lb 1,531 lbf ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Engine and powertrain: 84 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours
