▶ EngineEngine Manufacturer MHI Mitsubishi Engine Model S3L2-W463GTAC Not Published Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI 3-cylinder, turbocharged & aftercooled, Tier 4 B/Final No. of Cylinders 3 3 Displacement 80.4 in³ 80.4 in³ Rated Engine Speed 2500 rpm 2500 rpm Engine Power (Gross) 24.6 hp 24.6 hp PTO Power 19.2 hp 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System IDI (indirect injection) Not Published Alternator 50 A, 12 V Not Published ▶ HydraulicsPump Type Gear pump Not Published Implement Flow 7.9 gpm 7.9 gpm Steering Flow 4.6 gpm Not Published Total Hydraulic Flow 12.5 gpm Not Published Overall Hydraulic Pump Flow 12.5 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 (1 pair optional) 0 No. of Optional Remote Valves 1 pair (optional) 1 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 7.4 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1433 lb 1,433 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle hydrostatic (optional) No. of Speeds F12 x R12 infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Dry clutch Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Not Published Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119 in 117.2 in Overall Width 66 in Not Published Wheelbase 66 in 65.9 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 11.5 ft (3.5 m) Not Published Height to Top of ROPS 95 in 88.2 in Height to Top of ROPS (folded) Not Published 68.2 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,985 lb 2,469 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R4 industrial, R3 turf and VT (versa turf); VT same size as R4 Not Published R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 27x8.50-15 Not Published R4 Industrial - Rear 43x16.00-20 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler Not Published Loader Model LL3002 L330 Loader Lift Height LL3002: 94.3 in 94.3 in Loader Lift Capacity (Full Height) LL3002: 1,599 lb 1214 lb Loader Breakout Force LL3002: 2,962 lb 1926 lb ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 6-year extended warranty: 2 years bumper-to-bumper plus 4 additional years of powertrain protection
