▶ EngineEngine Manufacturer MHI Yanmar Engine Model S3L2-W463GTAC 3TNV80F-NXDKTFX Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.7 hp PTO Power 19.2 hp 18.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry Single dry Fuel System IDI (indirect injection) IDI Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Single gear pump Implement Flow 7.9 gpm 4.17 gpm Steering Flow 4.6 gpm 2.77 gpm Total Hydraulic Flow 12.5 gpm 6.94 gpm Overall Hydraulic Pump Flow 12.5 gpm 6.94 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 (1 pair optional) Not Published No. of Optional Remote Valves 1 pair (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 8.4 gal Coolant Capacity Not Published 3.8 qt Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published 4.49 gal Front Axle Fluid Capacity Not Published 4.7 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Available (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,550 lb Hitch Lift Capacity (at 24”) 1433 lb 1,235 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle HST No. of Speeds F12 x R12 2 Max Travel Speed (Forward) Not Published 13.57 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydraulic Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Adjustable suspension seat w/ armrests Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119 in 105.11 in Overall Width 66 in 56.29 in Wheelbase 66 in 61.02 in Ground Clearance Not Published 10.23 in Min. Turn Radius without Brakes 11.5 ft (3.5 m) 110.23 in Height to Top of ROPS 95 in 85.94 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,985 lb 2,206.8 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R4 industrial, R3 turf and VT (versa turf); VT same size as R4 R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 25x8.50-14 23x8.5-12 R3 Turf - Rear 41x14.00-20 33x12.5-16.5 R4 Industrial - Front 27x8.50-15 23x8.5-14 R4 Industrial - Rear 43x16.00-20 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler L2025P: Quick attach mechanism Loader Model LL3002 L2025P Loader Lift Height LL3002: 94.3 in L2025P: 87.7 in Loader Lift Capacity (Full Height) LL3002: 1,599 lb L2025P: 1,380 lb Loader Breakout Force LL3002: 2,962 lb L2025P: 2,059 lb ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
