▶ EngineEngine Manufacturer MHI Yanmar Engine Model S3L2-W463GTAC 3TNV80F Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI 3-cylinder, liquid-cooled diesel (natural aspiration) No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.7 hp PTO Power 19.2 hp 18.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System IDI (indirect injection) Direct fuel injection Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Single gear pump with flow divider Implement Flow 7.9 gpm 4.18 gpm Steering Flow 4.6 gpm 2.77 gpm Total Hydraulic Flow 12.5 gpm 6.95 gpm Overall Hydraulic Pump Flow 12.5 gpm 6.95 gpm Hydraulic System Type Open center Live, independent, open centre Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 1 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 6.6 gal Coolant Capacity Not Published 3.8 qt Crankcase Capacity Not Published 2.9 qt Transmission / Hydraulic System Capacity Not Published 5.8 gal Front Axle Fluid Capacity Not Published 4.7 qt ▶ PTO & HitchPTO Type Transmission driven Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1433 lb 1,534 lb Hitch Lift Capacity (at 24”) 1433 lb 1,102 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle 2-range hydrostatic No. of Speeds F12 x R12 2 Range Max Travel Speed (Forward) Not Published 13.7 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) 4WD with mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Rigid unit: transmission case, engine and front axle support bolted together Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Suspension seat with armrests & retractable seat belt Front Axle Type Front wheel mechanical assist (4WD) 4WD, center-pivot reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119 in 107.8 in Overall Width 66 in 52.8 in Wheelbase 66 in 61 in Ground Clearance Not Published 7.71 in Min. Turn Radius without Brakes 11.5 ft (3.5 m) 109.5 in Height to Top of ROPS 95 in 89.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,963 lb 1,881 lb Weight with ROPS and Loader Not Published 2,560 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 7-14 6-12 R1 Agricultural - Rear 11.2-24 9.5-20 R3 Turf - Front 25x8.50-14 25x8.5-14 R3 Turf - Rear 41x14.00-20 36x13.5-15 R4 Industrial - Front 27x8.50-15 23x8.5-12 (with 12-16.5 rear); 25x8.5-14 (with 14-17.5 rear) R4 Industrial - Rear 43x16.00-20 12-16.5 (with 23x8.5-12 front); 14-17.5 (with 25x8.5-14 front) ▶ Loader & AttachmentsQuick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler L85: skid-steer compatible quick-attach Loader Model LL3001 and LL3002 L85 Loader Lift Height LL3001 and LL3002: 94.3 in (at pivot pin) L85: 87.2 in (maximum lift height to pivot pin) Loader Lift Capacity (Full Height) LL3001 and LL3002: 1,599 lb (at pivot pin, maximum height) L85: 1,380 lb (at pivot pin, to full height) Loader Breakout Force LL3001 and LL3002: 2,962 lb (at pivot pin) L85: 2,059 lb (at ground level, pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Full machine: 2 years or 2,000 hours; Powertrain: 8 years or 3,000 hours (no deductible, parts and labor) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
