▶ EngineEngine Manufacturer MHI Yanmar Engine Model S3L2-W463GTAC 3TNV80F Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.7 hp PTO Power 19.2 hp 18.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Single dry Fuel System IDI (indirect injection) IDI Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Single gear pump Implement Flow 7.9 gpm 4.2 gpm Steering Flow 4.6 gpm 2.8 gpm Total Hydraulic Flow 12.5 gpm 6.9 gpm Overall Hydraulic Pump Flow 12.5 gpm 6.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 6.6 gal Coolant Capacity Not Published 3.8 qt Crankcase Capacity Not Published 2.9 qt Transmission / Hydraulic System Capacity Not Published 4.5 gal Front Axle Fluid Capacity Not Published 4.7 qt ▶ PTO & HitchPTO Type Transmission driven Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Available (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 1,551 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,230 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle HST No. of Speeds F12 x R12 Infinite 2-Range Max Travel Speed (Forward) Not Published 13.7 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Heavy duty mechanical suspension seat, manually adjustable for weight Front Axle Type Front wheel mechanical assist (4WD) 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66 in 50 in Wheelbase 66 in 61 in Ground Clearance Not Published 10.2 in Min. Turn Radius without Brakes Not Published 111.8 in Height to Top of ROPS 95 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 119 in (frame to link) 102.8 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,963 lb 2,046 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, VT and Turf; VT same size as Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 6-12 4PR R1 Agricultural - Rear 11.2-24 9.5-20 6PR R3 Turf - Front 25x8.50-14 Turf Master 23x8.50-12 NHS TL 4PR R3 Turf - Rear 41x14.00-20 Multi-Trac CS 33x12.50-16.5 NHS TL 4PR R4 Industrial - Front 27x8.50-15 Trac Chief 23x8.50-14 NHS TL 4PR R4 Industrial - Rear 43x16.00-20 36X12.5-15 ▶ Loader & AttachmentsQuick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler TL25: Quick attach mechanism Loader Model LL3001 and LL3002 TL25 Loader Lift Height LL3001 and LL3002: 94.3 in TL25: 87.2 in Loader Lift Capacity (Full Height) LL3001 and LL3002: 1,599 lb (at pivot pin, maximum height) TL25: 1,380 lb (at pivot pin) Loader Breakout Force LL3001 and LL3002: 2,962 lb (at pivot pin) TL25: 2,059 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Two-year bumper to bumper; six-year limited powertrain Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
