Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
LSMT226HE
No photo
—
BadBoy1025
Comparison loaded for 2 tractors.
Spec
LS TractorMT226HE
Bad Boy Tractors1025
PTO Power
17.1 hp (12.8 kW)
18.8 hp
Alternator
12 V, 50 A
12 V, 40 A
Air Cleaner
Dry
Single element
Engine Type
3-cylinder, Liquid-cooled, Diesel, NA, IDI
Water cooled, 4-cycle diesel
Fuel System
IDI
Injection pump (indirect)
Displacement
80.4 in³ (1318 cc)
77.3 in³ (1,267 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,500 rpm
3,000 rpm
Cooling System Type
Liquid-cooled
Water cooled, forced circulation
Engine Manufacturer
MHI
Yanmar
Engine Emissions Constraints
Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 24.6 hp (18.3 kW)
24.6 hp (18.4 kW / 25.0 PS) @ 3,000 rpm
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Applicable
Weight with ROPS and Loader
Not Published
1,610 lb (730 kg)
Pump Type
Gear pump
Gear pump
Steering Flow
17.4 L/min (4.6 gpm)
10.5 L/min (2.8 gpm)
Implement Flow
26.9 L/min (7.1 gpm)
15.8 L/min (4.2 gpm)
Total Hydraulic Flow
44.3 L/min (11.7 gpm)
25.7 L/min (7.0 gpm)
Hydraulic System Type
Open center
Power Assisted Hydro-Static
Rear Remote Hydraulic Flow
Not Published
Not Applicable
Overall Hydraulic Pump Flow
44.3 L/min (11.7 gpm)
26.3 L/min (6.95 gpm)
No. of Optional Remote Valves
1
Not Published
No. of Standard Remote Valves
0
Not Applicable
R3 Turf - Rear
41X14.00-20
29X12.5-15
R3 Turf - Front
25X8.50-14
20X8-10
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 (Ag) / R3 (Turf) / R4 (Industrial)
R4 Industrial - Rear
43X16.00-20
27X12-16.5
R4 Industrial - Front
27X8.50-15
23X8.5-12
R1 Agricultural - Rear
11.2-24
9.5-16
R1 Agricultural - Front
7-14
6-12
PTO Rear
540 rpm
540 rpm @ 2,893 engine rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1808 lb (820 kg)
1,323 lb (600 kg)
Mid-PTO Availability
Available (option)
Yes (2,000 rpm @ 2,875 engine rpm)
Category, 3-Point Hitch
Category I
Category I (N)
Hitch Lift Capacity (at 24”)
1433 lb (650 kg)
1,101 lb @ 24 in behind lift point
Rear 3-Point Hitch Lift Capacity
1808 lb (820 kg)
1,323 lb (600 kg)
Coolant Capacity
Not Published
0.96 gal (3.6 L)
Crankcase Capacity
Not Published
0.71 gal (2.7 L)
Fuel Tank Capacity
10.6 gal (40.1 L)
5.81 gal (22 L)
Front Axle Fluid Capacity
Not Published
0.85 gal (3.2 L)
Transmission / Hydraulic System Capacity
Not Published
3.83 gal (14.5 L)
Loader Lift Height
94.3 in (2395 mm)
75.5 in (pivot pin)
Loader Breakout Force
2,962 lb
1,531 lb (pivot pin, ground level)
Price for Backhoe Option
Not Published
Not Published
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
LL3001, LL3002: ISO 24410 Quick Attaching Coupler
Yes (quick attach)
Loader Lift Capacity (Full Height)
1,965 lb
992 lb (pivot pin)
Clutch
Not Applicable
No
No. of Speeds
3 ranges
2 range (Low/High)
Transmission Type
Hydrostatic Drive
HST (Hydro Max)
Max Travel Speed (Forward)
Not Published
10.5 mph (16.9 km/h) (H range, Ag tires)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Mechanical differential lock (pedal)
Differential lock
Brakes
Wet, Multi-disc
Wet disc, foot-operated
Steering
Hydrostatic power steering
Power steering (hydrostatic)
Frame Type
Not Published
Sub-compact tractor; selectable 4WD
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Not Published
Wheelbase
66 in (1676 mm)
57.5 in (1,460 mm)
Overall Width
66 in (1676 mm)
45.8 in (1,163 mm)
Ground Clearance
Not Published
9.4 in (240 mm)
Height to Top of ROPS
95 in (2413 mm)
91.3 in (2,320 mm)
Height to Top of Cab Model
Not Applicable
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
11.5 ft (3.5 m)
Not Published
Overall Length with 3-Point Hitch
119 in (3023 mm)
104.0 in (2,633 mm)
Financing Options
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
