▶ EngineEngine Manufacturer MHI Yanmar Engine Model S3L2-W463GTAC 3TNV80F Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.7 hp PTO Power 17.1 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry Fuel System IDI (indirect injection) In-line injection pump Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Gear pump, transmission driven Implement Flow 7.1 gpm 4.6 gpm Steering Flow 4.6 gpm 2.1 gpm Total Hydraulic Flow 11.7 gpm 6.7 gpm Overall Hydraulic Pump Flow 11.7 gpm 6.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None None No. of Optional Remote Valves 1 pair (optional) 1 set (2 quick couplers, optional) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 6.6 gal Coolant Capacity Not Published 0.9 gal Crankcase Capacity Not Published 0.8 gal Transmission / Hydraulic System Capacity Not Published 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear Standard (540 rpm) Standard (540 rpm) Mid-PTO Availability Available (option) Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 992 lb Hitch Lift Capacity (at 24”) 1,433 lb 728 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic Drive No. of Speeds 3 ranges 2 ranges Max Travel Speed (Forward) Not Published 8.70 mph Max Travel Speed (Reverse) Not Published 5.22 mph Clutch Not Published N/A Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Adjustable forward and backward via seat lever; reversible seat optional Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Width 66 in 47 in Wheelbase 66 in 56 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.8 ft (3.3 m) 7.87 ft Height to Top of ROPS 95 in 87 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 119 in (frame to link) 97 in (bumper to link) ▶ WeightTractor Weight (Base) 3,007 lb 1,444 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, VT and Turf; VT same size as Industrial Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 25x8.50-14 18x8.50-10 R3 Turf - Rear 41x14.00-20 26x12.0-12 R4 Industrial - Front 27x8.50-15 18x8.50-10 R4 Industrial - Rear 43x16.00-20 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler Not Published Loader Model LL3002 LL1102; LL1700; LL1001 Loader Lift Height LL3002: 94.3 in LL1001: 72.6 in (at pivot pin) Loader Lift Capacity (Full Height) LL3002: 1,599 lb (at pivot pin, maximum height) LL1001: 902 lb (at pivot pin, maximum height) Loader Breakout Force LL3002: 2,962 lb (at pivot pin) LL1001: 1,836 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Two-year bumper to bumper; six-year limited powertrain 6-year limited warranty
