▶ EngineEngine Manufacturer MHI Yanmar Engine Model S3L2-W463GTAC 3TNV80F-NXDKTFX Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 80.4 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.6 hp 24.7 hp PTO Power 17.1 hp 18.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry Single dry Fuel System IDI (indirect injection) IDI Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Gear pump Single gear pump Implement Flow 7.1 gpm 4.17 gpm Steering Flow 4.6 gpm 2.77 gpm Total Hydraulic Flow 11.7 gpm 6.94 gpm Overall Hydraulic Pump Flow 11.7 gpm 6.94 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 1 pair (optional) Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 8.4 gal Coolant Capacity Not Published 0.95 gal Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published 4.49 gal Front Axle Fluid Capacity Not Published 1.18 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Available (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,550 lb Hitch Lift Capacity (at 24”) 1,433 lb 560 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST HST No. of Speeds 3 ranges 2 Max Travel Speed (Forward) Not Published 13.57 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydraulic Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Mechanical suspension seat Front Axle Type Not Published Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66 in 56.29 in Wheelbase 66 in 61.02 in Ground Clearance Not Published 10.23 in Min. Turn Radius without Brakes 10.8 ft (3.3 m) 110.23 in Height to Top of ROPS 95 in 85.94 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 119 in (frame to link) 105.11 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,007 lb 2,207 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, VT and Turf; VT same size as Industrial R3 Turf, R4 Industrial, Hybrid R1 Agricultural - Front 7-14 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 25x8.50-14 23x8.5-12 R3 Turf - Rear 41x14.00-20 33x12.5-16.5 R4 Industrial - Front 27x8.50-15 23x8.5-14 R4 Industrial - Rear 43x16.00-20 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System LL3001, LL3002: ISO 24410 Quick Attaching Coupler L2025P: Quick attach mechanism Loader Model LL3002 L2025P Loader Lift Height LL3002: 94.3 in L2025P: 87.7 in Loader Lift Capacity (Full Height) LL3002: 1,599 lb (at pivot pin, maximum height) L2025P: 1,380 lb (at pivot pin) Loader Breakout Force LL3002: 2,962 lb (at pivot pin) L2025P: 2,059 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Two-year bumper to bumper; six-year limited powertrain Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
