Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
LSMT226HE
No photo
—
TYMT25
Comparison loaded for 2 tractors.
Spec
LS TractorMT226HE
TYMT25
PTO Power
17.1 hp (12.8 kW)
18.3 hp (13.6 kW)
Alternator
12 V, 50 A
12 V, 40 A
Air Cleaner
Dry
Single dry
Engine Type
3-cylinder, Liquid-cooled, Diesel, NA, IDI
3-cylinder, naturally aspirated diesel
Fuel System
IDI
IDI
Displacement
80.4 in³ (1318 cc)
77.3 in³ (1267 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,500 rpm
3,000 rpm
Cooling System Type
Liquid-cooled
Water-cooled
Engine Manufacturer
MHI
Yanmar 3TNV80F
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 24.6 hp (18.3 kW)
Gross: 24.7 hp (18.4 kW)
Tractor Weight with Loader
Not Published
2,726 lb (1,236 kg)
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
2,726 lb (1,236 kg)
Pump Type
Gear pump
Single gear pump
Steering Flow
17.4 L/min (4.6 gpm)
10.5 L/min (2.8 gpm)
Implement Flow
26.9 L/min (7.1 gpm)
15.8 L/min (4.2 gpm)
Total Hydraulic Flow
44.3 L/min (11.7 gpm)
26.3 L/min (6.9 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
44.3 L/min (11.7 gpm)
26.3 L/min (6.9 gpm)
No. of Optional Remote Valves
1
Not Published
No. of Standard Remote Valves
0
1
R3 Turf - Rear
41X14.00-20
Multi-Trac CS 33x12.50-16.5 NHS TL 4PR
R3 Turf - Front
25X8.50-14
Turf Master 23x8.50-12 NHS TL 4PR
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear
43X16.00-20
36x12.5-15; Trac Chief 14-17.5 NHS TL 6PR
R4 Industrial - Front
27X8.50-15
Trac Chief 23x8.50-14 NHS TL 4PR
R1 Agricultural - Rear
11.2-24
9.5-20 6PR
R1 Agricultural - Front
7-14
6-12 4PR
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1808 lb (820 kg)
1,551.2 lb (703.6 kg)
Mid-PTO Availability
Available (option)
Available (Mid-PTO kit)
Category, 3-Point Hitch
Category I
Category I
Hitch Lift Capacity (at 24”)
1433 lb (650 kg)
1,229.7 lb (557.8 kg)
Rear 3-Point Hitch Lift Capacity
1808 lb (820 kg)
1,551.2 lb (703.6 kg)
Coolant Capacity
Not Published
3.8 qt (3.6 L)
Crankcase Capacity
Not Published
2.9 qt (2.7 L)
Fuel Tank Capacity
10.6 gal (40.1 L)
6.6 gal (25 L)
Front Axle Fluid Capacity
Not Published
4.7 qt (4.5 L)
Transmission / Hydraulic System Capacity
Not Published
4.5 gal (17 L)
Loader Lift Height
94.3 in (2395 mm)
87.2 in (2215 mm)
Loader Breakout Force
2,962 lb
2,059 lb (934 kg)
Price for Backhoe Option
Not Published
TB65
Price for Mid-Mount Mower
Not Published
TM60
Quick Attach Loader System
LL3001, LL3002: ISO 24410 Quick Attaching Coupler
TL25: Quick attachment assembly
Loader Lift Capacity (Full Height)
1,965 lb
1,380 lb (626 kg)
Clutch
Not Applicable
Not Applicable
No. of Speeds
3 ranges
Infinite 2-Range
Transmission Type
Hydrostatic Drive
HST
Max Travel Speed (Forward)
Not Published
13.7 mph (22 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Mechanical differential lock (pedal)
Not Published
Brakes
Wet, Multi-disc
Wet disc
Steering
Hydrostatic power steering
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Heavy duty mechanical suspension; manual weight adjustment
Wheelbase
66 in (1676 mm)
61 in (1550 mm)
Overall Width
66 in (1676 mm)
50 in (1270 mm)
Ground Clearance
Not Published
10.2 in (260 mm)
Height to Top of ROPS
95 in (2413 mm)
91.3 in (2320 mm)
Height to Top of Cab Model
Not Applicable
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
11.5 ft (3.5 m)
111.8 in (2840 mm)
Overall Length with 3-Point Hitch
119 in (3023 mm)
102.8 in (2610 mm)
Financing Options
0% financing up to 96 months on select models; cash rebate incentive (offers vary)
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
