▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNV88F-EPLST 3TNV88F-EPJT2 Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, DI Diesel, naturally aspirated, direct injection No. of Cylinders 3 3 Displacement 100.2 in³ 100.2 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 19 hp 19.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water pump Air Cleaner Dry Dry type with safety element Fuel System DI (direct injection) Direct injection Alternator 55 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Gear pump Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 6.1 gpm 5.3 gpm Steering Flow 4.6 gpm 4.0 gpm Total Hydraulic Flow 10.7 gpm 9.3 gpm Overall Hydraulic Pump Flow 10.7 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 pair Not Published No. of Optional Remote Valves Not Published Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 11.4 gal 7.5 gal Coolant Capacity Not Published 5.2 qt Crankcase Capacity Not Published 4.5 qt Transmission / Hydraulic System Capacity Not Published 5.5 gal Front Axle Fluid Capacity Not Published 4 qt ▶ PTO & HitchPTO Type Independent Not Published PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 1,356 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type HST Hydrostatic transmission (HST) No. of Speeds 3 ranges Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Open operator station (OOS) Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD (MFWD) Front Axle Rating Not Published 1,760 lb Drawbar Capacity Not Published 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 66 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 69 in 62.8 in Ground Clearance Not Published 12.7 in (R4 tires) Min. Turn Radius without Brakes 11.5 ft (3.5 m) Not Published Height to Top of ROPS Not Published 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 90 in Not Published Overall Length 125 in (frame to link) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,609 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, VT and Turf; VT same size as Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 27X8.50-15 R3 Turf - Rear 41x14.00-20 41X14-20 R4 Industrial - Front 27x8.50-15 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 43x16.00-20 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System LL3002: ISO 24410 Quick Attaching Coupler Quick-change attachment carrier Loader Model LL3002 300E Loader Lift Height LL3002: 94.3 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) LL3002: 1,599 lb (at pivot pin, maximum height) 1,186 lb (at pivot pin) Loader Breakout Force LL3002: 2,962 lb (at pivot pin) 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Two-year bumper to bumper; six-year limited powertrain Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
