▶ EngineEngine Manufacturer YANMAR Kubota Engine Model 3TNV88C-MLST Not Published Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI Not Published No. of Cylinders 3 3 Displacement 100.2 in³ 91.5 in³ Rated Engine Speed 2600 rpm Not Published Engine Power (Gross) 31.7 hp 32.1 hp PTO Power 26.2 hp 25.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry Not Published Fuel System CRDI (common rail direct injection) Indirect injection Alternator 55 A, 12 V Not Published ▶ HydraulicsPump Type Gear pump Single pump (position-control) Implement Flow 6.7 gpm 8.3 gpm Steering Flow 5.0 gpm 4.9 gpm Total Hydraulic Flow 11.7 gpm 13.2 gpm Overall Hydraulic Pump Flow 11.7 gpm 13.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 pair Not Published No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 10.6 gal Coolant Capacity Not Published 6.3 qt Crankcase Capacity Not Published 6.0 qt Transmission / Hydraulic System Capacity Not Published 11.1 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent, hydraulic clutch PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Available (option) Optional mid-PTO, independent, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 3,750 lb (at lift points) Hitch Lift Capacity (at 24”) 1,433 lb 2,650 lb Lift Control Type Position control Position control (with optional draft control) ▶ Transmission & DrivetrainTransmission Type HST F (2WD), DT (4WD): 8-speed fully synchronized main and shuttle (16-speed with creep option) No. of Speeds 3 ranges 8F/8R (16F/16R with creep option) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry type single stage Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet disk type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66 in 56.3 in (minimum tread) Wheelbase 69 in 71.1 in Ground Clearance Not Published 14.6 in Min. Turn Radius without Brakes 11.5 ft (3.5 m) 8.9 ft (with brake applied) Height to Top of ROPS 95 in 88.8 in (with ROPS) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 125 in (frame to link) 119.1 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,254 lb 3,265 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, VT and Turf; VT same size as Industrial Standard Front: 7-16; Rear: 12.4-24 R1 Agricultural - Front 7-14 7-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 41x14.00-20 Not Published R4 Industrial - Front 27x8.50-15 Not Published R4 Industrial - Rear 43x16.00-20 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL3003: ISO 24410 Quick Attaching Coupler LA513 and LA723 loaders offered Loader Model LL3003, LL3004 LA513; LA723 Loader Lift Height LL3003, LL3004: 94.3 in LA513: 96.5 in; LA723: 102.4 in Loader Lift Capacity (Full Height) LL3003, LL3004: 2,063 lb (at pivot pin, maximum height) LA513: 1,345 lb; LA723: 1,870 lb Loader Breakout Force LL3003, LL3004: 3,723 lb (at pivot pin) LA513: 2,160 lbf (at 19.7 in); LA723: 2,605 lbf (at 19.7 in) (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Two-year bumper to bumper; six-year limited powertrain Not Published
