Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
LSMT232HE
No photo
—
KubotaL3302
Comparison loaded for 2 tractors.
Spec
LS TractorMT232HE
KubotaL3302
PTO Power
26.2 hp (19.5 kW)
DT (4WD): 28.0 hp (20.9 kW); HST (4WD): 26.1 hp (19.5 kW)
Alternator
12 V, 55 A
Not Published
Air Cleaner
Dry
Not Published
Engine Type
3-cylinder, Liquid-cooled, Diesel, NA, IDI
Direct injection, vertical, water-cooled 4-cycle, diesel
Fuel System
IDI
Direct injection
Displacement
100.2 in³ (1642 cc)
111.4 in³ (1826 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,600 rpm
2700 rpm
Cooling System Type
Liquid-cooled
Water-cooled
Engine Manufacturer
YANMAR
Kubota
Engine Emissions Constraints
Tier 4
Not Published
Engine Power (Gross vs. Net HP)
Gross: 31.7 hp (23.6 kW)
Gross: 33.0 hp (24.6 kW); Net: 31.8 hp (23.7 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Applicable
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Gear pump
Not Published
Steering Flow
18.9 L/min (5.0 gpm)
14.5 L/min (3.8 gpm)
Implement Flow
25.4 L/min (6.7 gpm)
23.9 L/min (6.3 gpm)
Total Hydraulic Flow
44.3 L/min (11.7 gpm)
38.4 L/min (10.1 gpm)
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
44.3 L/min (11.7 gpm)
38.4 L/min (10.1 gpm)
No. of Optional Remote Valves
1
Not Published
No. of Standard Remote Valves
0
Not Published
R3 Turf - Rear
41X14.00-20
13.6-16
R3 Turf - Front
25X8.50-14
25X8.50-14
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural; R3 Turf; R4 Industrial
R4 Industrial - Rear
43X16.00-20
15-19.5
R4 Industrial - Front
27X8.50-15
27X8.50-15
R1 Agricultural - Rear
11.2-24
11.2-24
R1 Agricultural - Front
7-14
7.2-16
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live independent PTO with hydraulic clutch
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1808 lb (820 kg)
1998 lb (906 kg)
Mid-PTO Availability
Available (option)
Not Published
Category, 3-Point Hitch
Category I
SAE Category I
Hitch Lift Capacity (at 24”)
1433 lb (650 kg)
1435 lb (651 kg)
Rear 3-Point Hitch Lift Capacity
1808 lb (820 kg)
1998 lb (906 kg)
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
10.6 gal (40.1 L)
13.5 gal (51 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
94.3 in (2395 mm)
94.3 in (2394 mm)
Loader Breakout Force
3,723 lb
Not Published
Price for Backhoe Option
Not Published
BH77: $9,803 MSRP
Price for Mid-Mount Mower
Not Published
Not Applicable
Quick Attach Loader System
LL3003: ISO 24410 Quick Attaching Coupler
Front Loader (LA526 — 2 Lever Quick Coupler (OPT))
Loader Lift Capacity (Full Height)
2,506 lb
1144.4 lb (519 kg)
Clutch
Not Applicable
DT (4WD): Dry type single stage; HST (4WD): Not Applicable
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
