▶ EnginePTO Power 35.4 hp 36.3 hp Alternator 55 A, 12 V 55 A, 12 V Air Cleaner Dry Dual element Engine Type 4-cylinder, Liquid-cooled, Diesel, NA, CRDI Turbocharged diesel; high pressure common rail direct injection Fuel System CRDI High pressure common rail direct injection Displacement 133.6 in³ 95.8 in³ No. of Cylinders 4 3 Rated Engine Speed 2600 rpm 2800 rpm Cooling System Type Liquid-cooled Liquid Engine Manufacturer YANMAR Yanmar Engine Power (Gross) 42.5 hp 41.6 hp @ 800 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Applicable ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) ▶ HydraulicsPump Type Gear pump Single gear Steering Flow 5.0 gpm 4.4 gpm Implement Flow 7.4 gpm 5.9 gpm Total Hydraulic Flow 12.4 gpm 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 12.4 gpm 10.3 gpm No. of Optional Remote Valves 1 Up to 2 (optional) No. of Standard Remote Valves 0 0 ▶ PTO & HitchPTO Rear 540 rpm 540 rpm @ 2400 engine rpm PTO Type Independent Transmission Lift Control Type Position control Position control Hitch Lift Capacity 1808 lb 2081.2 lb Mid-PTO Availability Available (option) Not Published Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity (at 24”) 1433 lb 2081.2 lb ▶ Tire OptionsR3 Turf - Rear 41X14.00-20 41X14-20 R3 Turf - Front 25X8.50-14 27X8.50-15 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R4 Industrial - Rear 43X16.00-20 15-19.5 R4 Industrial - Front 27X8.50-15 25X8.50-14 R1 Agricultural - Rear 11.2-24 11.2-24 R1 Agricultural - Front 7-14 7-14 ▶ Fluid CapacityCoolant Capacity Not Published Not Published Crankcase Capacity Not Published 1.2 gal Fuel Tank Capacity 10.6 gal 9.7 gal Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published 8.7 gal ▶ Loader & AttachmentsLoader Lift Height 94.3 in 84.0 in Loader Breakout Force 3,723 lb 1704 lb Quick Attach Loader System LL3003: ISO 24410 Quick Attaching Coupler Quick-change attachment carrier Loader Lift Capacity (Full Height) 2,506 lb 1186 lb ▶ Transmission & DrivetrainClutch Dry Single Single dry traction (mechanical) No. of Speeds F12 x R12 8F/8R Transmission Type Synchro Shuttle 8F/8R synchromesh shuttle shift gear transmission Max Travel Speed (Forward) Not Published 12.9 mph Max Travel Speed (Reverse) Not Published 13.5 mph Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Differential lock: Yes ▶ Chassis, Steering & ControlsBrakes Wet, Multi-disc Wet disk Steering Hydrostatic power steering Power steering Frame Type Not Published Not Published Front Axle Type Not Published 4WD Drawbar Capacity Not Published Not Published Front Axle Rating Not Published 1940 lb Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 74 in 62.0 in Overall Width 66 in 57.3 in Ground Clearance Not Published 13.0-13.9 in (331-13.9 in) Height to Top of ROPS 95 in Not Published Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 11.8 ft (3.6 m) 9.2 ft (2.8 m) Overall Length with 3-Point Hitch 125 in 111.2 in
