▶ EnginePTO Power 28 hp 28.5 hp Alternator 70 A, 12 V 55 A, 12 V Air Cleaner Dry Dry Engine Type 4-stroke, vertical, water cooling, CRDI 3-cylinder, Liquid-cooled, Diesel, NA, IDI Fuel System Delphi, CRDI IDI Displacement 114.7 in³ 100.2 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 2600 rpm Cooling System Type Water-cooled Liquid-cooled Engine Manufacturer LS Mtron YANMAR Engine Power (Gross) 35 hp 31.7 hp Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty ▶ HydraulicsPump Type Gear pump, engine drive Gear pump Steering Flow 5.5 gpm 5.0 gpm Implement Flow 7.8 gpm 7.4 gpm Total Hydraulic Flow 13.3 gpm 12.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 13.3 gpm 12.4 gpm No. of Optional Remote Valves Not Published 1 No. of Standard Remote Valves 2 Pair 0 ▶ PTO & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent PTO with wet disk clutch Independent Lift Control Type Position & Draft Position control Hitch Lift Capacity 1,808 lbs 1808 lb Mid-PTO Availability Option (2,000 rpm) Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1,433 lbs 1433 lb ▶ Tire OptionsR3 Turf - Rear 41X14-20 41X14.00-20 R3 Turf - Front 25X8.5-14 25X8.50-14 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 43X16-20 43X16.00-20 R4 Industrial - Front 25X8.5-14 27X8.50-15 R1 Agricultural - Rear 11.2-24 11.2-24 R1 Agricultural - Front 7.0-14 7-14 ▶ Fluid CapacityCoolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Fuel Tank Capacity 10.6 gal 10.6 gal Front Axle Fluid Capacity 1.7 gal Not Published Transmission / Hydraulic System Capacity 7.9 gal Not Published ▶ Loader & AttachmentsLoader Lift Height 94.4 in 94.3 in Loader Breakout Force 3,612 lbs 3,723 lb Quick Attach Loader System LL3116: Standard Skid Steer Coupler (skid-steer compatible quick-attach) LL3003: ISO 24410 Quick Attaching Coupler Loader Lift Capacity (Full Height) 2,185 lbs 2,506 lb ▶ Transmission & DrivetrainClutch Not Applicable Dry Single No. of Speeds 2 Pedal with 3 Range - HST F12 x R12 Transmission Type Hydrostatic Drive Synchro Shuttle Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsBrakes Wet, Multi-disc Wet, Multi-disc Steering Hydrostatic Power Steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Not Published Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 69.1 in 69 in Overall Width 59.3 in 66 in Ground Clearance Not Published Not Published Height to Top of ROPS 94.0 in 95 in Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 11.5 ft (3.5 m) Overall Length with 3-Point Hitch 136.1 in 125 in
