▶ EngineEngine Manufacturer LS Mtron LS Engine Model L3C19-T L3C19-T5 Engine Type 3 Cylinder, CRDI, water-cooled turbo diesel Vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 28 hp XR3135, XR3135C (gear): 29.7 hp; XR3135H, XR3135HC (HST): 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry Dry Fuel System CRDI CRDI (common rail direct injection) Alternator 85 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear pump, engine drive Gear pump, engine driven Implement Flow 8.2 gpm 8.2 gpm Steering Flow 5.5 gpm XR3135, XR3135C (gear): 4.1 gpm; XR3135H, XR3135HC (HST): 5.5 gpm Total Hydraulic Flow 13.7 gpm XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm Overall Hydraulic Pump Flow 13.7 gpm XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pair 2 pairs No. of Optional Remote Valves Not Published Optional (2 or 6 quick couplers) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal XR3135, XR3135H (ROPS): 10.6 gal; XR3135C, XR3135HC (cab): 12.4 gal Coolant Capacity Not Published 1.9 gal Crankcase Capacity Not Published 1.5 gal Transmission / Hydraulic System Capacity Not Published 7.9 gal Front Axle Fluid Capacity Not Published 1.7 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm (3-speed 540/750/1000 optional) Mid-PTO Availability Optional (2,000 rpm) Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) Not Published 1,433 lb Lift Control Type Position & Draft Position and draft control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) XR3135, XR3135C (gear): Synchro shuttle; XR3135H, XR3135HC (HST): HST No. of Speeds Infinite, 3 ranges (HST) XR3135, XR3135C (gear): F12 x R12; XR3135H, XR3135HC (HST): 3 ranges (HST) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Mechanical: dry single clutch; HST: not applicable Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 62 in Wheelbase 66 in 69 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS 93 in 94 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable 86.6 in Overall Length 124.3 in (frame to link) 128.3 in (bumper to link) ▶ WeightTractor Weight (Base) 3,285 lb XR3135 (gear, ROPS): 3,175 lb; XR3135H (HST, ROPS): 3,285 lb; XR3135C (gear, cab): 3,589 lb; XR3135HC (HST, cab): 3,655 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf Ag, industrial or turf tires at no additional cost R1 Agricultural - Front 9.5-16 7-14 R1 Agricultural - Rear 14.9-24 11.2-24 R3 Turf - Front 25x8.5-14 25x8.5-14 R3 Turf - Rear 41x14-20 41x14-20 R4 Industrial - Front 25x8.5-14 25x8.5-14 R4 Industrial - Rear 43x16-20 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System LL3116 LL3106, LL3116: quick attach, skid steer compatible Loader Model Not Published LL3106; LL3116 Loader Lift Height Not Published LL3106: 92.7 in; LL3116: 94.4 in Loader Lift Capacity (Full Height) LL3116: 2,185 lb LL3106: 2,178 lb; LL3116: 2,185 lb (at pivot pin) Loader Breakout Force Not Published LL3106: 3,450 lb; LL3116: 3,612 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty 6-year limited warranty
