▶ EngineEngine Manufacturer LS Mtron Shibaura Engine Model L3C19-T N3LDI-T Engine Type Vertical, water-cooled, 4 cycle diesel 3-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 3 3 Displacement 114.7 in³ 101.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power 32 hp 31.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry Fuel System CRDI Common rail direct injection Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear pump, engine drive Engine-driven gear-type pump Implement Flow 8.2 gpm Not Published Steering Flow 5.5 gpm Not Published Total Hydraulic Flow 13.7 gpm Not Published Overall Hydraulic Pump Flow 13.7 gpm 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves Not Published Cab: 1 pair No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 12.4 gal 10.56 gal Coolant Capacity Not Published 6.34 qt Crankcase Capacity Not Published 4.86 qt Transmission / Hydraulic System Capacity Not Published 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Front Axle Fluid Capacity Not Published 7.9 qt ▶ PTO & HitchPTO Type Independent Independent, with soft-start feature PTO Rear 540 rpm 540 rpm (6-spline) Mid-PTO Availability Optional (2,000 rpm) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I with extendable ball ends Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2,535 lb Lift Control Type Position & Draft Draft control optional ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 3 ranges (HST) 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single stage dry type Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Power steering Brakes Wet, Multi-disc Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Not Published Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Front Axle Type Not Published Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 64.2 in Wheelbase 69 in 69.7 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 99.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 86.6 in 91.3 in Overall Length 128.3 in (frame to link) 122.0 in ▶ WeightTractor Weight (Base) 3,661 lb 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, Industrial, Turf Agricultural, Turf, Industrial, Snow R1 Agricultural - Front 7-14 8-16 R1 Agricultural - Rear 11.2-24 12.4x24 R3 Turf - Front 25x8.5-14 27x8.50-15 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 25x8.5-14 10-16.5 R4 Industrial - Rear 43x16-20 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL3116 DL125: Pin-on (skid steer quick attach optional) Loader Model Not Published DL125 Loader Lift Height Not Published DL125: 106 in (at pivot pin) Loader Lift Capacity (Full Height) LL3116: 2,185 lb DL125: 1,660 lb (at pivot pin, full height) Loader Breakout Force Not Published DL125: 3,000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty Five-year powertrain warranty
