▶ EngineEngine Manufacturer LS Mtron Kubota Engine Model L4C25-T V2403-CR-E4-GL5 Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 4 4 Displacement 152.85 in³ 148.5 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 63 hp 62 hp PTO Power 54.1 hp 53 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry paper, dual element Fuel System Delphi, CRDI Electronic Common Rail System (CRS) Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Gear type, engine drive Tandem pump - gear type Implement Flow 14.5 gpm 9.4 gpm Steering Flow 6.6 gpm 4.7 gpm Total Hydraulic Flow 21.1 gpm 14.1 gpm Overall Hydraulic Pump Flow 21.1 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) Not Published No. of Optional Remote Valves Not Published Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity 24.3 gal 13.5 gal Coolant Capacity 3.0 gal 8.7 qt Crankcase Capacity 1.8 gal 9.9 qt Transmission / Hydraulic System Capacity 16.5 gal 11.9 gal Front Axle Fluid Capacity 2.3 gal 8.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 / 540E 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category II SAE Category I & II Hitch Lift Capacity 4,079 lb 3,858 lb Hitch Lift Capacity (at 24”) 3,483 lb 2,976 lb Lift Control Type Position & Draft Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic transmission No. of Speeds F16 x R16 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.2 mph Clutch Dry single clutch Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Wet disc type, mechanically activated Seat Suspension & Adjustability Seat With Suspension & Armrest Suspension seat with fore/aft travel adjustment, suspension adjust knob, backrest tilt adjustment, swivel and arm rest Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 140 in 135.0 in Overall Width 72.6 in 67.3 in Wheelbase 83.1 in 75.4 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes 12.8 ft (3.9 m) 9.2 ft (with brake applied) Height to Top of ROPS 113.9 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Applicable ▶ WeightTractor Weight (Base) 5,313 lb 3,990 lb Weight with ROPS and Loader 6,503 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 9.5-24 (Standard Ag); 11.2-24 (Large Ag) 9.5-16 R1 Agricultural - Rear 16.9-28 (Standard Ag); 16.9-30 (Large Ag) 14.9-26; 13.6-28 R3 Turf - Front Not Published 29X12.50-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front 10.5/80x18 10PR 10-16.5 R4 Industrial - Rear 19.5Lx24 8PR 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model LL5001 LA1055 Loader Lift Height LL5001: 132.9 in (height position); 116.8 in (power position) 112.7 in Loader Lift Capacity (Full Height) LL5001: 3,426 lb (height position); 3,488 lb (power position) 2361 lb Loader Breakout Force Not Published 3171 lbf (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
