▶ EngineEngine Manufacturer LS Mtron Kubota Engine Model L4C25-T V2403CR-T Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 152.85 in³ 148.6 in³ Rated Engine Speed 2500 rpm 2700 rpm Engine Power (Gross) 63 hp 63.4 hp PTO Power 54.1 hp 51.8 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry-dual element Fuel System Delphi, CRDI Common Rail System (CRS), direct injection Alternator 70 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Gear type, engine drive Gear Implement Flow 14.5 gpm 9.5 gpm Steering Flow 6.6 gpm 4.9 gpm Total Hydraulic Flow 21.1 gpm 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow 21.1 gpm 14.4 gpm (9.5 + 4.9, computed) Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) Not Published No. of Optional Remote Valves Not Published Maximum 3 (opt) ▶ Fluid CapacityFuel Tank Capacity 24.3 gal 13.5 gal Coolant Capacity 3.0 gal 6.9 qt Crankcase Capacity 1.8 gal 7.4 qt Transmission / Hydraulic System Capacity 16.5 gal 11.6 gal Front Axle Fluid Capacity 2.3 gal 8.9 qt ▶ PTO & HitchPTO Type Independent Live independent, hydraulic PTO with PTO brake, wet clutch PTO Rear 540 / 540E 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II I & II Hitch Lift Capacity 4,079 lb 2870 lb Hitch Lift Capacity (at 24”) 3,483 lb 2310 lb Lift Control Type Position & Draft Position (std), Draft (opt) ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic transmission No. of Speeds F16 x R16 3-range Max Travel Speed (Forward) Not Published 17.7 mph Max Travel Speed (Reverse) Not Published 16.0 mph Clutch Dry single clutch No clutch Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Mechanical wet disc Seat Suspension & Adjustability Seat With Suspension & Armrest High-back suspension seat (optional arm rests) Front Axle Type Not Published Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1650 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 140 in 125.9 in (without 3-point hitch) Overall Width 72.6 in 69.7 in Wheelbase 83.1 in 74.6 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes 12.8 ft (3.9 m) 8.9 ft (with brake applied) Height to Top of ROPS 113.9 in 95.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 92.7 in ▶ WeightTractor Weight (Base) 5,313 lb 3,734 lb Weight with ROPS and Loader 6,503 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D Standard ag: 9.5-16 / 14.9-26 R1 Agricultural - Front 9.5-24 (Standard Ag); 11.2-24 (Large Ag) 9.5-16 R1 Agricultural - Rear 16.9-28 (Standard Ag); 16.9-30 (Large Ag) 14.9-26 R3 Turf - Front Not Published 29x12.50-15 R3 Turf - Rear Not Published 44x18-20 R4 Industrial - Front 10.5/80x18 10PR 12-16.5 R4 Industrial - Rear 19.5Lx24 8PR 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) 1065A: 2-Lever Quick Coupler for Loader Attachment Loader Model LL5001 LA1065 Loader Lift Height LL5001: 132.9 in (height position); 116.8 in (power position) 111.2 in Loader Lift Capacity (Full Height) LL5001: 3,426 lb (height position); 3,488 lb (power position) 2275 lb Loader Breakout Force Not Published 3102 lbf (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 72 months or 3000 hours. Commercial Use - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
