▶ EngineEngine Manufacturer LS Mtron FPT Engine Model L4C25-T S8000 Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Turbocharged 3-cylinder diesel No. of Cylinders 4 3 Displacement 152.85 in³ 179 in³ Rated Engine Speed 2500 rpm 2300 rpm Engine Power (Gross) 63 hp 64 hp PTO Power 54.1 hp 50 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Dry PowerCore dry air cleaner Fuel System Delphi, CRDI Bosch electronic high-pressure common rail Alternator 70 A, 12 V 120 A ▶ HydraulicsPump Type Gear type, engine drive Dual gear pumps Implement Flow 14.5 gpm 12.6 gpm Steering Flow 6.6 gpm 7.6 gpm Total Hydraulic Flow 21.1 gpm 20.2 gpm Overall Hydraulic Pump Flow 21.1 gpm 20.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 24.3 gal 21.7 gal Coolant Capacity 3.0 gal Not Published Crankcase Capacity 1.8 gal Not Published Transmission / Hydraulic System Capacity 16.5 gal Not Published Front Axle Fluid Capacity 2.3 gal Not Published ▶ PTO & HitchPTO Type Independent Fully independent, hydraulic wet clutch PTO Rear 540 / 540E 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category I/II Hitch Lift Capacity 4,079 lb Not Published Hitch Lift Capacity (at 24”) 3,483 lb 3,500 lb (4,000 lb with optional auxiliary lift ram) Lift Control Type Position & Draft Lift-O-Matic with mechanical draft control (upper-link draft sensing) ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle 12x12 hydraulic power shuttle No. of Speeds F16 x R16 12F/12R Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single clutch 11 in single dry disc Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Hydraulic-assist wet brakes Seat Suspension & Adjustability Seat With Suspension & Armrest Cloth air-suspension seat with fold-back instructor seat Front Axle Type Not Published 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Front Axle Rating Not Published 6,500 lb dynamic capacity Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 140 in 154.1 in Overall Width 72.6 in Not Published Wheelbase 83.1 in 83.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 12.8 ft (3.9 m) Not Published Height to Top of ROPS 113.9 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 100.2 in ▶ WeightTractor Weight (Base) 5,313 lb 6,800 lb (cab, 4WD) Weight with ROPS and Loader 6,503 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) R1 Agricultural - Front 9.5-24 (Standard Ag); 11.2-24 (Large Ag) 11.2x24 R1, 6 ply R1 Agricultural - Rear 16.9-28 (Standard Ag); 16.9-30 (Large Ag) 16.9x30 R1, 6 ply R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10.5/80x18 10PR 12.5/80-18 R4, 10 ply R4 Industrial - Rear 19.5Lx24 8PR 19.5L-24 R4, 10 ply ▶ Loader & AttachmentsQuick Attach Loader System LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) 72 in bucket with SSL (skid steer) or Euro-style quick attach Loader Model LL5001 550LU (non self-leveling); 555LU (mechanical self-leveling) Loader Lift Height LL5001: 132.9 in (height position); 116.8 in (power position) 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) Loader Lift Capacity (Full Height) LL5001: 3,426 lb (height position); 3,488 lb (power position) 550LU: 2,425 lb; 555LU: 3,153 lb (at max height, 31.5 in ahead of bucket pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty Not Published
