▶ EnginePTO Power 54.1 hp (40.3 kW) 53.0 hp (39.5 kW) Alternator 12 V, 70 A HST (4WD): 12 V, 45 A; HSTC (4WD, CAB): 12 V, 60 A Air Cleaner Dry Dry paper, dual element Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged Fuel System Delphi, CRDI Electronic Common Rail System (CRS) Displacement 152.86 in³ (2505 cc) 148.5 in³ (2,434 cc) No. of Cylinders 4 4 Rated Engine Speed 2,500 rpm 2600 rpm Cooling System Type Water-cooled Liquid-cooled Engine Manufacturer LS Mtron Kubota Engine Emissions Constraints Tier 4 EPA Tier 4 Final (DPF muffler + EGR) Engine Power (Gross vs. Net HP) Gross: 63.0 hp (47.0 kW) Gross: 62.0 hp (46.3 kW); Net: 60.0 hp (44.8 kW) ▶ WeightTractor Weight with Loader 6,966 lb (3,160 kg) Not Published Weight with Cab and Loader 6,966 lb (3,160 kg) Not Published Weight with ROPS and Loader Not Applicable Not Published ▶ HydraulicsPump Type Gear type, engine drive Tandem pump - gear type Steering Flow 25.7 L/min (6.8 gpm) 4.7 gpm (17.9 L/min) Implement Flow 56.4 L/min (14.9 gpm) 9.4 gpm (35.6 L/min) Total Hydraulic Flow 82.1 L/min (21.7 gpm) 14.1 gpm (53.5 L/min) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 82.1 L/min (21.7 gpm) 14.1 gpm (53.5 L/min) No. of Optional Remote Valves Not Published Optional, up to 3 (double-acting valve or float detent valve options, any position) No. of Standard Remote Valves 2 Pairs (Front), 2 Pairs (Rear) Not Published ▶ Tire OptionsR3 Turf - Rear Not Published 44X18-20 R3 Turf - Front Not Published 29X12.50-15 Tire Size & Options Multiple options available (Standard Ag, Industrial, Large Ag, R14) Standard R1; Option 1 R4; Option 2 R3; LSW option (R3) R4 Industrial - Rear 19.5LX24 17.5L-24 R4 Industrial - Front 10.5/80X18 10-16.5 R1 Agricultural - Rear 16.9-30 14.9-26; 13.6-28 R1 Agricultural - Front 11.2-24 9.5-16 ▶ Pto & HitchPTO Rear 540 / 540E 540 rpm @ 2400 engine rpm PTO Type Independent Live independent (hydraulic clutch) Lift Control Type Position & Draft Position control Hitch Lift Capacity 4,079 lbs 3,858 lb Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category II SAE Category 1 & 2 Hitch Lift Capacity (at 24”) 3,483 lbs 2,976 lb Rear 3-Point Hitch Lift Capacity 4,079 lbs 3,858 lb ▶ Fluid CapacityCoolant Capacity 3.0 gal (11.5 L) 8.7 qt Crankcase Capacity 1.8 gal (7.0 L) 9.9 qt Fuel Tank Capacity 24.3 gal (92 L) 13.5 gal Front Axle Fluid Capacity 2.3 gal (8.6 L) Not Published Transmission / Hydraulic System Capacity 16.5 gal (62.5 L) 11.9 gal ▶ Loader & AttachmentsLoader Lift Height 132.9 in (3376 mm) 112.7 in (2862 mm) Loader Breakout Force Not Published 3171 lb (14107 N) Price for Backhoe Option Not Applicable BH92: $11,078 MSRP Price for Mid-Mount Mower Not Applicable Not Published Quick Attach Loader System LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Lift Capacity (Full Height) 3,488 lb 2361 lb (1071 kg) ▶ Transmission & DrivetrainClutch Dry single clutch N/A No. of Speeds F16 X R16 3-range, 6 speeds (H-DS), infinitely variable in each Transmission Type Synchro Shuttle Hydrostatic transmission Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.2 mph Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Rear differential lock, standard ▶ Chassis Steering & ControlsBrakes Wet, Multi-disc Wet disc type, mechanically activated Steering Hydrostatic Power Steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Drawbar Capacity Not Published 1,433 lbs. Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Seat With Suspension & Armrest Not Published ▶ Dimensions & ManeuverabilityWheelbase 83.1 in (2111 mm) 75.4 in (1915 mm) Overall Width 72.6 in (1844 mm) 67.3 in (1709 mm) Ground Clearance Not Published 15.4 in (391 mm) Height to Top of ROPS Not Applicable HST (4WD): 98.0 in (2489 mm); HSTC (4WD, CAB): Not Applicable Height to Top of Cab Model 105.4 in (2677 mm) HST (4WD): Not Applicable; HSTC (4WD, CAB): 92.5 in (2350 mm) Height to Top of ROPS (folded) Not Applicable HST (4WD): 92.5 in (2350 mm); HSTC (4WD, CAB): Not Applicable Min. Turn Radius without Brakes 12.8 ft (3.9 m) 9.2 ft (2.8 m) Overall Length with 3-Point Hitch 154 in (3912 mm) 135.0 in (3429 mm) ▶ Pricing Financing & WarrantyFinancing Options 0% financing up to 96 months on select models; cash rebate incentive (offers vary) Check with your local dealer for the best offer. Base Price with Loader Not Published HST (4WD): Tractor Starting MSRP $44,440 + LA1055 $6,710 = $51,150 MSRP; HSTC (4WD, CAB): Tractor Starting MSRP $54,848 + LA1055 $6,710 = $61,558 MSRP Warranty Length & Coverage 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Base Price with Loader + Cab Not Published HST (4WD): Not Applicable; HSTC (4WD, CAB): Tractor Starting MSRP $54,848 + LA1055 $6,710 = $61,558 MSRP ▶ SourcesSpec sheet sources [1] lstractorusa.com [2] lstractorusa.com [3] lstractorusa.com [4] lstractorusa.com [5] lstractorusa.com [6] lstractorusa.com [7] lstractorusa.com [1] kubotausa.com [2] kubotausa.com [3] kubotausa.com [4] kubotausa.com
